MULTIPORT FUEL INJECTION (MFI) DIAGNOSIS TSB Revision MULTIPORT FUEL INJECTION (MFI) 13A-923 NO : Check harness connectors D-208, D-221, E-111 at intermediate connector for damage, and repair or . If intermediate connector is in good condition, repair harness wire STEP 6. Check for continuity at fuel pump relay 2 harness harness side. (2) Check for the continuity between terminal No. 2 and ground. • Should be less than 2 ohms. Q: Does continuity exist? YES : Go to Step 7. connector B-24X (terminal No. 2) and ground AK201177 2 1 3 4 B-24X AB CONNECTOR: B-24X HARNESS AK201384 2 1 3 4 B-24X HARNESS AK201384AB 2 1 3 4 |
