M-ASTC DIAGNOSIS TSB Revision MITSUBISHI ACTIVE SKID AND TRACTION CONTROL SYSTEM 35C-91 STEP 17. Measure the voltage in the CAN_L line. Check at CAUTION Before checking CAN bus lines and their interconnected CAUTION When measuring resistance value or voltage in CAN bus M-ASTC-ECU connector E-121, and measure the voltage (2) Turn the ignition switch to the "ON" position. CAUTION Always use the test harness when measuring the voltage E-122 terminal 20 and body ground. • The voltage should measure 0.5 volts or more, or 4.5 volts or less. Q: Does the voltage measure 0.5 volts or more, or 4.5 volts or less? AC204194 CONNECTORS: E-121, E-122 E-121 HARNESS SIDE E-121 E-122(L) FEMALE CONNECTOR AH E-122(L) 71 77 83 72 78 84 73 79 85 74 80 75 81 86 76 82 87 11 22 10 21 9 20 8 19 7 18 6 17 5 16 4 15 3 14 2 13 1 12 AC204580 FEMALE CONNECTOR: E-122 AB 11 22 10 21 9 20 8 19 7 18 6 17 5 16 4 15 3 14 2 13 1 12 TEST |
