TSB Revision DIAGNOSTIC TROUBLE CODE PROCEDURES 13Ac-129 STEP 2. Check for short circuit to power supply between YES : Replace the PCM. Then go to Step 3. STEP 3. Perform the OBD-II drive cycle. GROUP 13A, Trouble Code Diagnosis − OBD-II Drive Cycle − Procedure 6 − Other Monitor (2) Check the diagnostic trouble code (DTC). YES : Repeat the troubleshooting. AK201274 1 2 3 4 CONNECTOR: B-07 B-07(B) AB HARNESS RIGHT BANK AK200947 91 92 93 94 95 96 97 98 99 100 101 102 103 104 105 106 107 108 109 110 111 112 113 114 115 116 117 118 119 120 CONNECTOR: D-135 HARNESS CONNECTOR: AB PCM D-135(GR) |
