TSB Revision DIAGNOSTIC TROUBLE CODE PROCEDURES 13Ac-89 P0123 Throttle Position Sensor (Main) Circuit high Input . CIRCUIT OPERATION • A 5-volt power supply is applied on the TPS (main) power terminal (terminal No. 2) from the • When the throttle valve shaft is turned from the idle position to the fully opened position, the . TECHNICAL DESCRIPTION • The TPS (main) outputs voltage which corre- sponds to the throttle valve opening angle. AK201130 RED WHITE BLA CK B-05 5 V 106 2 THROTTLE POWERTRAIN CONTROL MODULE (PCM) 115 105 1 4 Throttle Position Sensor (Main) Circuit 9192 939495 96979899 100 105 113114 115116117 118119120 106 107108109 110111112 101102103 104 D-135 (MU803805) 6 1 2 3 4 5 AK201173 THROTTLE AB B-05(B) CONNECTOR: B-05 AK201038AF CONNECTOR: D-135 PCM D-135(GR) |
