ON-VEHICLE SERVICE TSB Revision POWER STEERING 37A-19 POWER STEERING FLUID REPLACEMENT M1372002100258 1. Jack up the front wheels and support them. .) 3. Connect a vinyl hose to the return hose A, and drain the fluid into a container. 4. Disconnect the ignition coil connector. (Refer to GROUP 16, 5. While operating the starting motor intermittently, turn the steering wheel all the way to the left and right several times 6. Connect the return hose A securely, and then secure with the clip. 7. Fill the oil reservoir with GENUINE MITSUBISHI POWER STEERING FLUID up to the lower position of the filler, and POWER STEERING SYSTEM AIR BLEEDING M1372002200255 1. Jack up the front wheels and support them. CAUTION • During air bleeding, fill fluid so that its level is always higher than the MIN line on the oil reservoir. • If the air bleeding is performed by operating the engine, air will break into small particles and melt into fluid. Be • If the steering wheel is turned all the way to the right and left at the engine stop condition, the fluid may leak 3. Turn the steering wheel all the way to the left and right five or six times while using the starter motor to crank the engine 4. Connect the ignition coil. Start the engine (idling). air bubbles in the oil reservoir. 6. Confirm that the fluid is not milky, and that the level is between the high and low dipstick marks. 7. Confirm that there is very little change in the fluid level when the steering wheel is turned left and right. ACX01132 AE RETURN VINYL HOSE |
