Mitsubishi Montero (2002-2004). Manual - part 194
MAINTENANCE SERVICE
TSB Revision
GENERAL <BODY AND CHASSIS>
00-45
(2) By referring to the section on coolant, select an
appropriate concentration for safe operating temperature
within the range of 30 to 60%. Refill the system with a
high quality ethylene glycol antifreeze at the selected
concentration. A convenient mixture is a 50% water and
50% antifreeze solution [freezing point:
−31°C (−32.8°F)].
Pour in coolant until it overflows from the air bleed bolt
hole, and then tighten the air bleed bolt.
8. <When special tool MB991871 is used>
By referring to the section on coolant, select an appropriate
concentration for safe operating temperature within the
range of 30 to 60 %. Use special tool MB991871 to refill the
coolant. A convenient mixture is a 50 % water and 50 %
antifreeze solution [freezing point:
−31°C (−32.8 °F)].
NOTE: For how to use special tool MB991871, refer to its
manufacturer’s instructions.
Recommended antifreeze:
Long life antifreeze coolant or an equivalent
Quantity: 9.0 dm
3
(9.5 quarts)
9. Reinstall the radiator cap.
10.Start the engine and let it warm up until the thermostat
opens.
11.After repeatedly revving the engine up to 3,000 r/min several
times, then stop the engine.
12.Remove the radiator cap after the engine has become cold,
and pour in coolant up to the brim. Reinstall the cap.
CAUTION
Do not overfill the reserve tank.
13.Add coolant to the reserve tank between the "FULL" and
"LOW" mark if necessary.
15. DISC BRAKE PADS (INSPECT FOR WEAR)
M1001003200138
Check for fluid contamination and wear. Replace the complete
set of pads if defective.
Thickness of lining
Minimum limit: 2.0 mm (0.08 inch)
CAUTION
The pads for the right and left wheels should be replaced
at the same time. Never split or intermix brake pad sets. All
four pads must be replaced as a complete set.
AC203797
AB
CAUTION LABEL
AIR BLEED BOLT
14±1 N·m
120±13 in-lb
AC204032
AB
AIR HOSE
MB991871
ACX00898 AB
