AUTOMATIC TRANSAXLE DIAGNOSIS TSB Revision AUTOMATIC TRANSAXLE 23A-51 STEP 4. Check the sensor output voltage at A/T control (1) Disconnect connector B-108 and measure at the harness side. (2) Turn the ignition switch to the "ON" position. (3) Measure the voltage between terminal 1 and ground. • The voltage should measure between 4.5 and 4.9 volts. (4) Turn the ignition switch to the "LOCK" (OFF) position. YES : Go to Step 5. AC306322 CONNECTOR: B-108 B-108 (GR) AC TRANSMISSION 2 7 1 8 3 9 4 6 10 5 2 5 6 10 4 9 3 8 1 7 AC201006AE B-108 HARNESS |
