SUNROOF ASSEMBLY TSB Revision BODY 42-79 SUNROOF INITIALIZATION M1426004600123 The sunroof should be initialized when any of the following • Roof lid glass assembly • Sunroof motor assembly . 1. Ensure the components are correctly assembled. Ensure all the connectors are connected securely. 2. If the sunroof is already in learn mode, go to step 3. If the sunroof is not in learn mode, enter learn mode by (1) or (2) (1) Disconnect the sunroof motor assembly connector while the sunroof is operating. (2) Stop the sunroof operation by fitting the block (board etc.). Then press and hold the sunroof close switch for 10 3. Press the sunroof Close switch repeatedly until the sunroof is tilted up fully. 4. Press and hold the sunroof Close switch for at least three seconds. 5. Press the sunroof Close switch until the sunroof closes fully. AC203084 AB |
