51-1

GROUP 51

EXTERIOR

CONTENTS

GENERAL INFORMATION . . . . . . . .

51-2

BUMPER  . . . . . . . . . . . . . . . . . . . . . .

51-3

RADIATOR GRILL . . . . . . . . . . . . . . .

51-4

WINDSHIELD WIPER AND WASHER

51-5

DOOR MIRRORS . . . . . . . . . . . . . . . .

51-6

GENERAL INFORMATION

EXTERIOR

51-2

GENERAL INFORMATION

M2510000100763

FEATURES

.

BETTER APPEARANCE
1. Comes with two types of radiator grill.
2. Comes with a front mud guard.
3. Comes with a rear spoiler. <GTS>

.

BETTER AERODYNAMIC CHARACTERISTICS
4. Comes with an under cover.
5. Comes with a rear spoiler. <GTS>

.

BETTER USER-FRIENDLINESS
6. Features power remote controlled door mirrors.
7. Features heated door mirrors.

.

BETTER PRODUCT PACKAGE
8. Comes with a vehicle speed sensitive intermittent

time variable windshield wiper.

.

SUPPORT RECYCLING OF RESOURCES
Aggressively uses PP (polypropylene) materials that
are easy to recycle and easy to stamp material sym-
bols on the plastic (resin) parts.

.

AC305789

8

1

6, 7

2

3, 5

AB

4

BUMPER

EXTERIOR

51-3

BUMPER

M2510002000290

The bumpers incorporate highly rigid bumper beams
and PC/PBT (polycarbonate/polybutylene
terephthalate) cores for excellent energy-absorption
to reduce chassis deformation upon impact.

CONSTRUCTION DIAGRAM

AC306249

ENERGY ABSORBER

CORE

BUMPER BEAM

AB

FRONT BUMPER

REAR BUMPER

FRONT BUMPER

REAR BUMPER

SECTION A - A

SECTION B - B

A

A

B

BUMPER BEAM

ENERGY ABSORBER

CORE

LICENSE

PLATE

GARNISH

B

RADIATOR GRILL

EXTERIOR

51-4

RADIATOR GRILL

M2510001000156

Two different  types of radiator grills are used.

CONSTRUCTION DIAGRAM

AC306188

<ES, LS, GTS>

<DE>

AB
