TOWING AND HOISTING

TSB Revision

GENERAL

00-27

TOWING WHEN KEYS ARE NOT AVAILABLE
When a locked vehicle must be towed and keys are not avail-
able, the vehicle may be lifted and towed from the front, pro-
vided the parking brake is released. If not released, the rear
wheels should be placed on a tow dolly.

.

SAFETY PRECAUTIONS
The following precautions should be taken when towing the
vehicle:

1. DO NOT LIFT OR TOW THE VEHICLE BY ATTACHING

TO OR WRAPPING AROUND THE BUMPER.

2. Any loose, protruding, or damaged parts such as hoods,

doors, fenders, trim, etc. should be secured or removed
prior to moving the vehicle.

3. Refrain from going under a vehicle when it is lifted by the

towing equipment, unless the vehicle is adequately sup-
ported by safety stands.

4. Never allow passengers to ride in a towed vehicle.
5. State and local rules and regulations must be followed when

towing a vehicle.

LIFTING, JACKING SUPPORT LOCATION

.

FLOOR JACK

CAUTION

• Never place a support at any point other than the speci-

fied one, or that point will be deformed.

• Any DTCs stored in the ABS-ECU cannot be erased if

there is a malfunction.

• For lifting, put rubber or similar material between the

side sill and rigid rack, otherwise  the side sill area will
be damaged.

AC308631AB

Side view

Under view

FRONT MUD
GUARD

TOWING AND HOISTING

TSB Revision

GENERAL

00-28

.

POST TYPE
Special care should be taken when raising the vehicle on a
frame contact type hoist. The hoist must be equipped with the
proper adapters in order to support the vehicle at the proper
locations.

AC307266AB

RUBBER

RIGID RACK

CENTER MEMBER

RIGID RACK

NOTCH

REAR SUSPENSION CROSSMEMBER

NOTCH

RUBBER

TOWING AND HOISTING

TSB Revision

GENERAL

00-29

CAUTION

• When service procedures require removing rear sus-

pension, fuel tank and spare tire, place additional
weight on the rear end of vehicle, or anchor vehicle to
hoist to prevent tipping when the location of the center
of gravity changes.

• If the assembling support area contacts with the front

mud guard (arrow area as shown in the illustration), the
front mud guard will be damaged. Slide the assembling
support area to the front of the vehicle slightly to pre-
vent the damage.

AC308631AB

Side view

Under view

FRONT MUD
GUARD

AC307269

NOTCH

AB

NOTCH

GENERAL DATA AND SPECIFICATIONS

TSB Revision

GENERAL

00-30

GENERAL DATA AND SPECIFICATIONS

M1001000900473

.

GENERAL SPECIFICATIONS

<2.4L ENGINE>

AC305137

4

8

6

3

7

5

9

1

2

ITEM

DJ1ASRJYL4M/S
RHYL4M/SL9M/L5
M

DJ1ASRPYL4M/S
L9M/L5M

DJ1ASRXYL4M/S
L9M/5M

Vehicle
dimension
mm (in)

Overall length

1 4,840 (190.6)

4,840 (190.6)

4,840 (190.6)

Overall width

2 1,840 (72.4)

1,840 (72.4)

1,840 (72.4)

Overall height (unladen)

3 1,470 (57.9)

1,470 (57.9)

1,470 (57.9)

Wheelbase

4 2,750 (108.3)

2,750 (108.3)

2,750 (108.3)

Tread-front

5 1,570 (61.8)

1,570 (61.8)

1,570 (61.8)

Tread-rear

6 1,570 (61.8)

1,570 (61.8)

1,570 (61.8)

Overhang-front

7 985 (38.8)

985 (38.8)

985 (38.8)

Overhang-rear

8 1,105 (43.5)

1,105 (43.5)

1,105 (43.5)

Ground clearance

9 148 (5.8)

148 (5.8)

148 (5.8)

Vehicle
weight kg (lb)

Curb weight

1,530 (3,373)

1,540 (3,395)

1,550 (3,417)

Gross vehicle weight rating

1,960 (4,321)

1,960 (4,321)

1,960 (4,321)

Gross axle weight
rating-front

1,040 (2,293)

1,040 (2,293)

1,040 (2,293)

Gross axle weight
rating-rear

9,20 (2,028)

9,20 (2,028)

9,20 (2,028)

Seating capacity

5

Engine

Model No.

4G69

Piston displacement

2.4L

Transaxle

Model No.

F4A42

Type

4-speed automatic

Fuel system

Fuel supply system

Electronic controlled multiport fuel injection
