VEHICLE IDENTIFICATION

TSB Revision

GENERAL

00-19

VEHICLE INFORMATION CODE PLATE

M1001005400440

The vehicle information code plate is riveted onto the cowl top
outer panel in the engine compartment.
The plate shows model code, engine model, transaxle model
and body color code.

For monotone color vehicles, the body color code shall be indi-
cated.

VEHICLE SAFETY CERTIFICATION LABEL

The vehicle safety certification label is attached to the face of
the left door inside sill.
This label indicates the month and year of manufacture, Gross
Vehicle Weight Rating (GVWR), front and rear Gross Axle
Weight Rating (GAWR), and Vehicle Identification Number
(VIN).

NO. ITEM

CONTENT

1

MODEL

DJ3ASRXE
L9M

DJ3AS: Vehicle model

RXEL9M: Model series

2

ENGINE

4G69

Engine model

6G75

3

EXT

W69D

Exterior code

4

TRANS

F4A4B

F4A4B:Transaxle model

F4A5A

F4A5A:Transaxle model

5

COLOR

W69

W69: Body color code

6

TRIM

08X

08X: Interior code

7

OPT

Z12

Z12: Equipment code

AC306967AB

1

2

3

4

5

6

7

AC306462

AB

VEHICLE IDENTIFICATION

TSB Revision

GENERAL

00-20

ENGINE MODEL STAMPING

The engine model is stamped on the cylinder block.
The engine model number is as shown as follow.

The engine serial number is stamped near the engine model
number.

THEFT PROTECTION

In order to protect against theft, a Vehicle Identification Number
(VIN) is attached as a plate or label to the following major parts
of the engine and transaxle, as well as main outer panels:
Engine cylinder block, Transaxle housing, Fender, Doors,
Trunk lid, Rear quarter outer panel, Hood, Bumpers
In addition, a theft-protection label is attached to replacement
parts for the body outer panel main components, and the same
data is stamped into replacement parts for the engine and the
transaxle.

CAUTION

Cautions regarding panel repairs:

1. When repainting original parts, do so after first masking

the theft-protection label. After painting, be sure to peel
off the masking tape.

2. The theft-protection label for replacement parts is cov-

ered by masking tape, so such parts can be painted as
is. The masking tape should be removed after painting
is finished.

3. The theft-protection label should not be removed from

original parts or replacement parts.

ENGINE MODEL

ENGINE DISPLACEMENT

4G69

2.4L

6G75

3.8L

AC306463

AB

<2.4L ENGINE>

<3.8L ENGINE>

AC211646

THEFT PROTECTION LABEL
FOR ORIGINAL PARTS

FOR REPLACEMENT PARTS

AB

VEHICLE IDENTIFICATION

TSB Revision

GENERAL

00-21

LOCATIONS

LABEL AREA (A: FOR ORIGINAL EQUIPMENT PARTS, B: FOR REPLACEMENT PARTS)

AC000058

ENGINE
<2.4L ENGINE>

AD

A

B

AC000061

ENGINE
<3.8L ENGINE>

AC

B

A

AC000060

AUTOMATIC TRANSAXLE

AB

A

B

AC307026AB

A

B

HOOD

AC307027

A

B

FENDER

THE ILLUSTRATION INDICATES
LEFT OUTER SIDE.
RIGHT SIDE IS SYMMETRICALLY
OPPOSITE.

AB

AC307028AB

A

B

REAR QUARTER OUTER PANEL

THE ILLUSTRATION INDICATES LEFT OUTER SIDE.
RIGHT SIDE IS SYMMETRICALLY OPPOSITE.

VEHICLE IDENTIFICATION

TSB Revision

GENERAL

00-22

LABEL AREA (A: FOR ORIGINAL EQUIPMENT PARTS, B: FOR REPLACEMENT PARTS)

AC307042AB

A

B

FRONT DOOR

THE ILLUSTRATION INDICATES LEFT INNER SIDE.
RIGHT SIDE IS SYMMETRICALLY OPPOSITE.

C

C

SECTION C-C

AC307044AB

A

B

REAR DOOR

THE ILLUSTRATION INDICATES LEFT INNER SIDE.
RIGHT SIDE IS SYMMETRICALLY OPPOSITE.

D

D

SECTION D-D

AC307046AB

A

B

TRUNK LID

 AC307067AB

B

A

FRONT BUMPER

AC307083AB

A

B

REAR BUMPER
