MULTI CENTER DISPLAY <MIDDLE>
TSB Revision
CIRCUIT DIAGRAMS
90-207
BATTERY
FRONT-ECU
TAILLIGHT
RELAY
RELAY
BOX
JUNCTION
BLOCK
WIRE COLOR CODE
B : BLACK LG : LIGHT GREEN G : GREEN L : BLUE
BR :BROWN O : ORANGE GR : GRAY R : RED W : WHITE
SB : SKY BLUE P : PINK Y : YELLOW V : VIOLET
JOINT
CONNECTOR (1)
·AUDIO SYSTEM
·AUTOMATIC AIR
CONDITIONING
SYSTEM
·DEFOGGER AND DOOR
MIRROR HEATER
·ELECTRONIC BRAKE-
FORCE DISTRIBUTION
(EBD) AND ANTI-LOCK
BRAKING SYSTEM (ABS)
<VEHICLES WITH
TRACTION CONTROL (TCL)>
·FOG LIGHT
·GLOVE BOX LIGHT
·HEATED SEAT
·INVECS-II 4A/T
·MANUAL AIR
CONDITIONING SYSTEM
·METER AND GAUGE
·RHEOSTAT
·SUPPLEMENTAL
RESTRAINT
SYSTEM (SRS)
·TURN-SIGNAL
LIGHT AND
HAZARD WARNING
LIGHT
·FOG LIGHT
·HEADLIGHT
·TAILLIGHT,
POSITION LIGHT,
FRONT SIDE
MARKER LIGHT
AND LICENSE
PLATE LIGHT
·TURN-SIGNAL
LIGHT AND
HAZARD
WARNING LIGHT
·WINDSHIELD
WIPER AND
WASHER
·AUDIO SYSTEM
·AUTO-CRUISE
CONTROL SYSTEM
·AUTOMATIC AIR
CONDITIONING
SYSTEM
·BRAKE WARNING
LIGHT, OIL PRESSURE
WARNING LIGHT,
FUEL WARNING LIGHT
·CENTRAL DOOR
LOCKING SYSTEM
·CHARGING SYSTEM
·CONTROLLER AREA
NETWORK (CAN)
·DOOR AJAR WARNING
TONE ALARM
·ELECTRONIC BRAKE-
FORCE DISTRIBUTION
(EBD) AND ANTI-LOCK
BRAKING SYSTEM (ABS)
·ENGINE IMMOBILIZER
SYSTEM
·FOG LIGHT
·FRONT DOME LIGHT,
REAR DOME LIGHT,
TRUNK LIGHT AND
IGNITION KEY HOLE
ILLUMINATION LIGHT
·HEADLIGHT
·INVECS-II 4A/T
·LIGHTING MONITOR
TONE ALARM
·MANUAL AIR
CONDITIONING SYSTEM
·METER AND GAUGE
·MFI SYSTEM
·SEAT BELT WARNING
TONE ALARM
·SUPPLEMENTAL
RESTRAINT SYSTEM
(SRS)
·TAILLIGHT, POSITION
LIGHT, FRONT SIDE
MARKER LIGHT AND
LICENSE PLATE LIGHT
·TURN-SIGNAL
LIGHT AND
HAZARD WARNING
LIGHT
·VANITY MIRROR LIGHT
·WINDSHIELD WIPER
AND WASHER
