AUDIO SYSTEM <VEHICLES WITH AUDIO AMPLIFIER>

TSB Revision

CIRCUIT DIAGRAMS

90-199

FUSIBLE
LINK

5

·POWER WINDOWS
·SUNROOF

·POWER SEAT

JUNCTION
BLOCK

RADIO, CD PLAYER AND CD CHANGER

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE
BR :BROWN     O : ORANGE     GR : GRAY     R : RED     W : WHITE
SB : SKY BLUE     P : PINK      Y : YELLOW     V : VIOLET

ANTENNA

FEEDER CABLE

ANTENNA

FEEDER CABLE

DIVERSITY
ANTENNA

AUDIO SYSTEM <VEHICLES WITH AUDIO AMPLIFIER>

TSB Revision

CIRCUIT DIAGRAMS

90-200

AUDIO SYSTEM <VEHICLES WITH AUDIO AMPLIFIER> (CONTINUED)

AUDIO AMPLIFIER

RADIO, CD PLAYER AND CD CHANGER

RHEOSTAT

MULTI
CENTER
DISPLAY
UNIT

WITH MULTI
CENTER
DISPLAY (LOW)

POWERTRAIN
CONTROL
MODULE

AUDIO SYSTEM <VEHICLES WITH AUDIO AMPLIFIER>

TSB Revision

CIRCUIT DIAGRAMS

90-201

POWERTRAIN CONTROL MODULE

ABS-ECU OR
ABS/TCL-ECU

JOINT
CONNECTOR (3)

DATA LINK
CONNECTOR

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW
SB : SKY BLUE     BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET

<WITH MULTI CENTER DISPLAY (MIDDLE)>

WITHOUT ELECTRONIC BRAKE-FORCE
DISTRIBUTION (EBD) AND ANTI-LOCK BRAKING
SYSTEM (ABS)
WITH ELECTRONIC BRAKE-FORCE
DISTRIBUTION (EBD) AND ANTI-LOCK BRAKING
SYSTEM (ABS)

NOTE

:

:

ACCESSORY SOCKET

TSB Revision

CIRCUIT DIAGRAMS

90-202

ACCESSORY SOCKET

M1901007900455

FUSIBLE
LINK

1

JUNCTION
BLOCK

ACCESSORY
SOCKET (2)

·AUTOMATIC AIR
 CONDITIONING SYSTEM
·CONTROLLER AREA
 NETWORK (CAN)
·MANUAL AIR
 CONDITIONING SYSTEM
·MULTI CENTER DISPLAY

·CENTRAL DOOR
 LOCKING SYSTEM
·CONTROLLER AREA
 NETWORK (CAN)
·FRONT DOME LIGHT,
 REAR DOME LIGHT,
 TRUNK LIGHT AND
 IGNITION KEY HOLE
 ILLUMINATION- LIGHT
·REMOTE CONTROLLED
 MIRROR

NOTE

:

:
