TYPE B (ACTUAL-MEASUREMENT DIMENSIONS)

TSB Revision

BODY DIMENSIONS

2-11

AB301121

AB

13

AB300722

AB

14

15

14, 15

AB301123

AB

17

16

18

16, 17, 18

AB301122

AB

19

20

19, 20

TYPE B (ACTUAL-MEASUREMENT DIMENSIONS)

TSB Revision

BODY DIMENSIONS

2-12

FRONT BODY

M4020006000142

AB300509AB

29

27

26

28

25

24

22

23

21

1,179

(46.3)

  953

(37.4)

  635

(24.9)

1,445

(56.7)

1,616

(63.5)

1,024

(40.2)

1,077

(42.3)

1,525

(59.9)

  474

(18.6)

1,474

(57.9)

  864

(33.9)

1,125

(44.2)

  909

(35.7)

  623

(24.5)

1,592

(62.5)

1,068

(41.9)

BODY CENTER POINT

BODY CENTER POINT

  868

(34.1)

mm (in)

  927

(36.4)

  520

(20.4)

  323

(12.7)

  748

(29.4)

AB300510

AB

21

30

31

  820

(32.2)

  605

(23.8)

  946

(37.2)

  405

(15.9)

  892

(35.0)

BODY CENTER POINT

TYPE B (ACTUAL-MEASUREMENT DIMENSIONS)

TSB Revision

BODY DIMENSIONS

2-13

NO. STANDARD MEASUREMENT POINT

HOLE SHAPE SIZE mm (in)

21

Center of hood lock stay mounting hole (Body center point)

Round

9 (0.4)

22

Center of front bumper reinforcement stay positioning hole

Round

13 (0.5)

23

Center of bumper reinforcement bracket mounting hole

Round

10 (0.4)

24

Center of front end upper bar mounting hole

Round

12 (0.5)

25

Center of front fender mounting hole

Round

6.6 (0.26)

26

Center of front suspension mounting hole

Round

11.5 (0.45)

27

Center of engine room insulator mounting hole (Body center point)

Round

7 (0.3)

28

Center of front upper frame extension inner positioning hole

Round

12 (0.5)

29

Corner of roof panel

−

−

30

Center of front end crossmember outer positioning hole

Round

10 (0.4)

31

Center of front end upper bar mounting hole

Round

14 (0.5)

AB300672

21

AB

AB300673

AB

22

AB300674

AB

30

23

23, 30

AB300675

AB

31

24

24, 31

AB300676

AB

25

AB300677

AB

26

AB300678

AB

27

AB300679

AB

28

AB300680

AB

29

TYPE B (ACTUAL-MEASUREMENT DIMENSIONS)

TSB Revision

BODY DIMENSIONS

2-14

SIDE BODY

M4020007000145

AB301154

AB

32

34

33

35

37

36

38

40

41

39

1,147

(45.0)

  983

(38.6)

1,195

(46.9)

1,129

(44.3)

  714

(28.0)

  651

(25.6)

  807

(31.7)

  894

(35.1)

  494

(19.4)

  881

(34.6)

  547

(21.5)

  961

(37.7)

mm (in)

  898

(35.3)

AB301195

AB

34

42

43

44

45

46

38

1,168

(45.9)

1,112

(43.7)

1,177

(46.2)

1,106

(43.4)

1,072

(42.1)

1,014

(39.8)

  340

(13.4)

  329

(12.9)

  844

(33.1)

  928

(36.4)
