BODY MAIN CROSS-SECTIONAL VIEWS

TSB Revision

BODY CONSTRUCTION

1-5

AB300731

G

H

I

J

K

L

AB

AB300862

AB

G

SIDE OUTER
PANEL

SIDE OUTER
REINFORCEMENT

CENTER PILLAR
INNER

CENTER PILLAR
SEATBELT
REINFORCEMENT

CENTER PILLAR
REINFORCEMENT
UPPER

CENTER PILLAR
REINFORCEMENT

AB300863

H

SIDE OUTER PANEL

SIDE ROOF RAIL
REINFORCEMENT REAR

REAR QUARTER
INNER PANEL UPPER

AB

AB300864

I

AB

ROOF REAR RAIL

ROOF PANEL

AB300865

J

AB

SIDE
OUTER
PANEL

SIDE OUTER
REINFORCEMENT

CENTER PILLAR
INNER

CENTER PILLAR
REINFORCEMENT

AB300866

AB

SIDE OUTER
PANEL

REAR QUARTER
INNER PANEL LOWER

REAR WHEEL
HOUSE PANEL
INNER

K

AB300867

AB

REAR END
PANEL INNER

REAR END
PANEL OUTER

L

TRUNK LID LOCK REINFORCEMENT

MAINTENANCE, SERVICEABILITY

TSB Revision

BODY CONSTRUCTION

1-6

MAINTENANCE, SERVICEABILITY

M4010003000175

FENDER SHIELD

Positioning holes, marks, and notches have been
provided at the following overlapped areas to
improve operation performance when replacing pan-
els.

AB301246

AB

MAINTENANCE, SERVICEABILITY

TSB Revision

BODY CONSTRUCTION

1-7

SIDE STRUCTURE

Panel positioning notches have been provided at the
door opening section to improve operation perfor-
mance when replacing panels.

SIDE OUTER PANEL

Spare parts are provided in the following cut form
with the adoption of the pillar integral type side outer
panel.

AB201388

AB301247AB

PANEL POSITIONING NOTCH

AB301236

CENTER PILLAR OUTER

FRONT PILLAR OUTER

FRONT FLOOR SIDE SILL OUTER

REAR QUARTER
OUTER PANEL

AB

BODY CONSTRUCTION CHARACTERISTICS

TSB Revision

BODY CONSTRUCTION

1-8

BODY CONSTRUCTION CHARACTERISTICS

FRONT BODY

M4010010000144

HEADLIGHT SUPPORT

AB300600AB

2

3

4

5

7

6

8

9

1

10

11

1.

FRONT END UPPER BAR

2.

FRONT END UPPER BAR SIDE

3.

G SENSOR PROTECTOR BRACKET

4.

HEADLIGHT SUPPORT PANEL

5.

RADIATOR SUPPORT PANEL

6.

FRONT BUMPER REINFORCEMENT STAY

7.

FRONT END CROSSMEMBER INNER

8.

RADIATOR LOWER BRACKET B

9.

RADIATOR LOWER BRACKET A

10. FRONT END CROSSMEMBER REINFORCEMENT
11. FRONT END CROSSMEMBER OUTER
