SENSOR
TSB Revision
COMPONENT LOCATIONS
70-8
SENSO R
M1701000600062
NAME
SYMBOL NAME
SYMBOL
A/C compressor assembly (with built-
in lock sensor) <3.0L Engine>
M
Left bank heated oxygen sensor
(rear) <3.0L Engine>
N
A/T control solenoid valve assembly
(with built-in A/T fluid temperature
sensor)
R
Manifold differential pressure sensor
<2.4L Engine>
A
Camshaft position sensor <2.4L
Engine>
I
Manifold differential pressure sensor
<3.0L Engine>
D
Crankshaft position sensor <2.4L
Engine>
K
Output shaft speed sensorS
Crankshaft position sensor <3.0L
Engine>
L
Right bank heated oxygen sensor
(front) <3.0L Engine>
B
Distributor assembly (with built-in top
dead center sensor) <3.0L Engine>
J
Right bank heated oxygen sensor
(rear) <3.0L Engine>
V
Engine coolant temperature sensor
<2.4L Engine>
H
Side impact sensor <Side air bag>
Z
Engine coolant temperature sensor
<3.0L Engine>
Q
Thermistor sensor <Heater and A/C> U
Fuel tank differential pressure sensor W
Throttle position sensor <2.4L
Engine>
F
Heated oxygen sensor (front) <2.4L
Engine>
O
Throttle position sensor <3.0L
Engine>
G
Heated oxygen sensor (rear) <2.4L
Engine>
Y
Vehicle speed sensorE
Ignition failure sensor <2.4L Engine>
A
Volume air flow sensor
T
Input shaft speed sensor
S
Wheel speed sensor (front)
X
Knock sensor <3.0L Engine>
C
Wheel speed sensor (rear)
a
Left bank heated oxygen sensor
(front) <3.0L Engine>
P
