AIR BAG MODULE DISPOSAL PROCEDURES TSB Revision SUPPLEMENTAL RESTRAINT SYSTEM(SRS) 52B-85 WARNING Store the air bag module on a flat surface with the pad 2. Remove the air bag module from the vehicle. (Refer to .) 3. Connect two wires, each 6 meters (20 feet) or longer, to the two leads of special tool MB686560, and cover the 4. Connect the deployment wires to special tool MB686560, pass it beneath the tire and wheel assembly, and connect it CAUTION • Leave some space below the wheel for the deployment • During deployment, the connector of special tool 5. Pass the thick wire through the air bag module mounting hole, and then secure the air bag module to an old tire with a 6. Place three old tires without wheels on top of the tire secured to the air bag module, and secure all tires together AC001932 CONNECTION DEPLOYMENT WIRES MR686560 INSULATOR TAPE 6 m(20 ft) AB ACX01314AB PASSENGER'S SIDE DEPLOYMENT ACX00611 TIRES WITHOUT DEPLOYMENT AB |
