Mitsubishi Galant. Manual - part 584





52A-2

GROUP 52A

INTERIOR

CONTENTS

GENERAL INFORMATION . . . . . . . .

52A-3

GENERAL DESCRIPTION . . . . . . . . . . . . .

52A-3

SEAT BELT DIAGNOSIS. . . . . . . . . .

52A-3

SEAT BELT WARNING SYSTEM DIAGNOSIS

 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

52A-3

SPECIAL TOOLS. . . . . . . . . . . . . . . .

52A-3

INSTRUMENT PANEL ASSEMBLY  .

52A-4

REMOVAL AND INSTALLATION   . . . . . . .

52A-4

DISASSEMBLY AND ASSEMBLY . . . . . . .

52A-10

FLOOR CONSOLE ASSEMBLY . . . .

52A-11

REMOVAL AND INSTALLATION . . . . . . . .

52A-11

TRIMS. . . . . . . . . . . . . . . . . . . . . . . . .

52A-12

 REMOVAL AND INSTALLATION  . . . . . . .

52A-12

HEADLINING . . . . . . . . . . . . . . . . . . .

52A-14

REMOVAL AND INSTALLATION . . . . . . . .

52A-14

INSIDE REAR VIEW MIRROR . . . . . .

52A-15

REMOVAL AND INSTALLATION  . . . . . . . .

52A-15

FRONT SEAT ASSEMBLY. . . . . . . . .

52A-15

REMOVAL AND INSTALLATION  . . . . . . . .

52A-15

DISASSEMBLY AND ASSEMBLY  . . . . . . .

52A-16

INSPECTION. . . . . . . . . . . . . . . . . . . . . . . .

52A-18

REAR SEAT ASSEMBLY. . . . . . . . . .

52A-20

REMOVAL AND INSTALLATION  . . . . . . . .

52A-20

DISASSEMBLY AND ASSEMBLY  . . . . . . .

52A-21

FRONT SEAT BELT . . . . . . . . . . . . . .

52A-22

REMOVAL AND INSTALLATION  . . . . . . . .

52A-22

INSPECTION. . . . . . . . . . . . . . . . . . . . . . . .

52A-22

REAR SEAT BELT . . . . . . . . . . . . . . .

52A-23

REMOVAL AND INSTALLATION  . . . . . . . .

52A-23

SPECIFICATIONS  . . . . . . . . . . . . . . .

52A-24

FASTENER TIGHTENING SPECIFICATIONS

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

52A-24

WARNINGS REGARDING SERVICING OF SUPPLEMENTAL RESTRAINT SYSTEM (SRS) EQUIPPED VEHICLES

WARNING

••••

Improper service or maintenance of any component of the SRS, or any SRS-related component, can lead to
personal injury or death to service personnel (from inadvertent firing of the air bag) or to the driver and
paassenger (from rendering the SRS inoperative).

••••

Service or maintenance of any SRS component or SRS-related component must be performed only at an
authorized MITSUBISHI dealer.

••••

MITSUBISHI dealer personnel must thoroughly review this manual, and especially its GROUP 52B - Supplemental
Restraint System (SRS) before beginning any service or maintenance of any component of the SRS or any SRS-
related component.

NOTE
The SRS includes the following components: SRS air bag control unit, SRS warning light, front impact sensors, air bag module,
clock spring, and interconnecting wiring. Other SRS-related components (that may have to be removed/installed in connection
with SRS service or maintenance) are indicated in the table of contents by an asterisk (*).

GENERAL INFORMATION

TSB Revision

INTERIOR

52A-3

.

G EN ER A L IN FO R M ATIO N

GENERAL DESCRIPTION

M1523000100038

OPERATION

Seat belt warning system

When the ignition switch is turned "ON" without fastening the seat belts (seat belt switch OFF), the tone
alarm will sound for approximately 6 seconds to warn the driver to fasten the seat belts.When the seat
belts are fastened, the torn alarm will stop sounding.

When the ignition switch is turned ON without fastening the seat belt, the seat belt warning light comes on
to warn the driver to fasten the seat belt.

SEAT B ELT D IA G N O SIS

SEAT BELT WARNING SYSTEM DIAGNOSIS

M1521000700078

The seat belt warning system is controlled by Simplified Wiring System (SWS). For troubleshooting, refer to
GROUP 54B, SWS Diagnosis

P.54B-104

.

SPECIA L TO O LS

M1521000600071

TOOL

TOOL NUMBER AND
NAME

SUPERSESSION

APPLICATION

MB990784
Ornament remover

General service tool

Removal of switch, trim,
etc.

MB990784

INSTRUMENT PANEL ASSEMBLY

TSB Revision

INTERIOR

52A-4

IN STRU M ENT PA N EL A SSEM BLY

REMOVAL AND INSTALLATION

M1521001700071

WARNING

For removal and installation of the passenger's side air bag module, always observe the
service procedures described in GROUP 52B, Air Bag Module and Clock Spring

P.52B-67

.

The bolts and screws described below are used for installation of the instrument panel. They are indicated by
symbols in the illustration.

MB991502
Scan tool (MUT-II)

MB991496-OD

Checking the ETACS-
ECU input signal

MB991529
Diagnostic trouble code
check harness

Tool not necessary if
scan tool (MUT-II) is
available

Checking the ETACS-
ECU input signal
(When using the
voltmeter)

MB991223
A: MB991219
B: MB991220
C: MB991221
D: MB991222
Harness set
A: Test harness
B: LED harness
C: LED harness
D: Probe

MB991223

Measurement of terminal
voltage

TOOL

TOOL NUMBER AND
NAME

SUPERSESSION

APPLICATION

B991502

MB991529

MB991223

A

B

C

D

AE
