Mitsubishi Galant. Manual - part 568





DOOR

TSB Revision

BODY

42-55

Required Special Tool:

MB990784: Ornament Remover

INSPECTION

M1429001600093

POWER WINDOW SWITCH CONTINUITY CHECK

Power window main switch's front <LH> switch check
Connect the terminal number 13 to the battery (+) post, and the
terminal number 12 to the battery (-) post.

Main switch

NOTE: *: Set switch to UNLOCK position

Sub switch

5. POWER WINDOW (MAIN OR SUB)

SWITCH

6. POWER WINDOW SWITCH PANEL
7. DOOR WEATHERSTRIP LOWER
8. PULL HANDLE BOX BRACKET

REMOVAL STEPS (Continued)

9. DOOR INSIDE HANDLE
10. WATERPROOF FILM

REMOVAL STEPS (Continued)

SWITCH POSITION

TESTER
CONNECTION

SPECIFIED
CONDITION

FRONT (LH)

UP

 13, 9

 12,

Continuity

OFF

 9

 12

Continuity

DOWN

 13, 8

 12

Continuity

FRONT (RH)

UP

 13, 11

 12*

Continuity

OFF

 11, 3 -11

 12*

Continuity

DOWN

11

 13, 3

 12*

Continuity

REAR (LH)

UP

 13, 2

 12*

Continuity

OFF

 2, 1

 2

 12*

Continuity

DOWN

 13, 1

 12*

Continuity

REAR (RH)

UP

13

 14, 6

 12*

Continuity

OFF

 14, 6

 12*

 14 Continuity

DOWN

 13, 12

 14*

Continuity

SWITCH POSITION

TESTER
CONNECTION

SPECIFIED
CONDITION

Sub switch

UP

 5, 6

 7

Continuity

OFF

 5, 6

 8

Continuity

DOWN

 7, 6

 8

Continuity

AC000577

18I0342

5

4

6

13

3

2

1

14

12

11

10

9

8

7

AC000585

1

2 3

4 5 6 7 8

DOOR

TSB Revision

BODY

42-56

DOOR GLASS AND REGULATOR

REMOVAL AND INSTALLATION

M1429001300070

Pre-removal Operation

Door Trim and Waterproof Film Removal (Refer to

P.42-

54

.)

Post-installation Operation

Door Window Glass Adjustment (Refer to

P.42-49

.)

Door Trim and Waterproof Film Removal (Refer to

P.42-

54

.)

AC000601

1

2

3

5

9

6

7

4

8

9

10

4

6

5

7

12

11

FRONT DOOR

REAR DOOR

RELAY BOX IN ENGIN

COMPARTMENT

AB

1. POWER WINDOW RELAY
2. FRONT-ECU
3. ETACS-ECU
DOOR WINDOW GLASS AND DOOR
WINDOW REGULATOR ASSEMBLY
REMOVAL STEPS
4. DOOR WINDOW INNER

WEATHERSTRIP

5. DOOR BELTLINE MOLDING
6. DOOR WINDOW GLASS HOLDER

>>A<<

7. DOOR WINDOW GLASS

8. DOOR INNER LOWER IMPACT-

ABSORBING CORE <FRONT DOOR
ONLY>

9. DOOR WINDOW REGULATOR

ASSEMBLY

STATIONARY WINDOW GLASS
REMOVAL STEPS

<<A>>

10. DOOR CENTER SASH
11. STATIONARY WINDOW

WEATHERSTRIP

12. STATIONARY WINDOW GLASS

DOOR WINDOW GLASS AND DOOR
WINDOW REGULATOR ASSEMBLY
REMOVAL STEPS (Continued)

DOOR

TSB Revision

BODY

42-57

REMOVAL SERVICE POINT

<<A>> DOOR CENTER SASH REMOVAL
1. Remove the door outer opening weatherstrip from the door

center sash only.

2. Remove the door center sash mounting screws, and then

remove the door center sash from the door panel.

INSTALLATION SERVICE POINT

>>A<< DOOR WINDOW GLASS INSTALLATION
1. Temporarily secure the door window glass to the door

window regulator.

2. After raising the door window glass as far as it will go, fully

secure the door window glass to the door window regulator
assembly.

NOTE: When the door window glass is closed fully, the door
limit switch will be reset.

INSPECTION

M1429001400088

POWER WINDOW RELAY CONTINUITY CHECK

POWER WINDOW MOTOR CHECK

1. Connect a battery directly to the motor terminals and check

that the motor runs smoothly.

2. Check that the motor runs in the opposite direction when the

battery is connected with the polarity reversed.

3. If defect is found, replace the window regulator as an

assembly.

AC000602

DOOR OUTER

OPENING

WEATHERSTRIP

DOOR CENTER

SASH

AB

BATTERY
VOLTAGE

TESTER
CONNECTION

SPECIFIED
CONDITION

Not applied

 3

Continuity

1-Battery (-)
terminal,3-battery
(+)terminal

 5

Continuity

1

2 3

4

5

1

3

4

5

ACX01544

2

1

AC003900 AB

SLIDER

DOOR

TSB Revision

BODY

42-58

DOOR HANDLE AND LATCH

REMOVAL AND INSTALLATION

M1423004600094

Pre-removal Operation

Door Trim and Waterproof Film Removal (Refer to

P.42-

54

.)

Post-installation Operation

Door Inside Handle Play Check (Refer t

P.42-50

.)

Door Outside Handle Play Check (Refer to

P.42-50

.)

Door Trim and Waterproof Film Installation (Refer to

P.42-

54

.)

AC000603AB

1

2

3

4

7

6

12

11

5

2

10

8

9

12

FRONT DOOR

REAR DOOR

6 N·m

53 in-lb

6 N·m

53 in-lb

1. ETACS-ECU
FRONT DOOR HANDLE AND DOOR
LATCH ASSEMBLY REMOVAL STEPS
2. DOOR INSIDE HANDLE
3. DOOR OUTSIDE HANDLE
4. DOOR LOCK KEY CYLINDER
5. DOOR INNER LOWER IMPACT-AB-

SORBING CORE

6. REAR LOWER SASH
7. DOOR LATCH ASSEMBLY

REAR DOOR HANDLE AND DOOR
LATCH ASSEMBLY REMOVAL STEPS
2. DOOR INSIDE HANDLE

DOOR CENTER SASH (REFER TO

P.42-56

.)

8. DOOR LATCH ASSEMBLY
9. DOOR LOCK ACTUATOR
10. DOOR OUTSIDE HANDLE

 DOOR CHECK REMOVAL STEPS
11. DOOR SPEAKER <FRONT DOOR

ONLY>

12. DOOR CHECK
