DOOR

TSB Revision

BODY

42-51

CIRCUIT BREAKER (INCORPORATED IN THE
POWER WINDOW MOTOR) INSPECTION

M1429001000057

1. Pull the power window switch to the UP position to fully

close the door window glass, and keep pulling the switch for
a further 10 seconds.

2. Release the power window switch from the UP position and

immediately press it to the DOWN position. The condition of
the circuit breaker is good if the door window glass starts to
move downwards within 60 seconds.

DOOR

TSB Revision

BODY

42-52

DOOR ASSEMBLY

REMOVAL AND INSTALLATION

M1423002200078

Post-installation Operation

•

Door Fit Adjustment (Refer to

P.42-48

.)

AC000597

7, 8

7

5

8

4

6

1

2

3

10

5

3

2

1

9

4

11

10, 11

FRONT DOOR

REAR DOOR

26 N·m

19 ft-lb

21 N·m

15 ft-lb

26 N·m

19 ft-lb

21 N·m

15 ft-lb

11 N·m

97 ft-lb

21 N·m

15 ft-lb

21 N·m

15 ft-lb

26 N·m

19 ft-lb

26 N·m

19 ft-lb

AB

11 N·m

97 ft-lb

1. DOOR SWITCH
STRIKER REMOVAL STEPS
2. STRIKER
3. STRIKER SHIM

FRONT DOOR ASSEMBLY REMOVAL
STEPS

•

FRONT SCUFF PLATE AND COWL
SIDE TRIM (REFER TO GROUP
52A, TRIMS

P.52A-12

.)

4. HARNESS CONNECTOR
5. DOOR CHECK INSTALLATION

BOLT

6. FRONT DOOR ASSEMBLY

DOOR

TSB Revision

BODY

42-53

INSTALLATION SERVICE POINT

>>A<< REAR DOOR LOWER HINGE/REAR DOOR UPPER
HINGE INSTALLATION
The rear door hinges differ according to where they are used,
so check identification mark before installation.

INSPECTION

M1423006000087

DOOR SWITCH CONTINUITY CHECK

7. FRONT DOOR UPPER HINGE
8. FRONT DOOR LOWER HINGE
REAR DOOR ASSEMBLY REMOVAL
STEPS

•

CENTER PILLAR LOWER TRIM
(REFER TO GROUP 52A, TRIMS

P.52A-12

.)

4. HARNESS CONNECTOR
5. DOOR CHECK INSTALLATION

BOLT

9. REAR DOOR ASSEMBLY

>>A<<

10. REAR DOOR UPPER HINGE

>>A<<

11. REAR DOOR LOWER HINGE

FRONT DOOR ASSEMBLY REMOVAL
STEPS (Continued)

APPLICABLE LOCATION

IDENTIFICATION
MARK

Rear left door

Upper hinge

M2

Lower hinge

O2

Rear right door

Upper hinge

N2

Lower hinge

P2

AC000598AB

REAR DOOR

UPPER HINGE

REAR DOOR

LOWER HINGE

IDENTIFICATION

MARK

IDENTIFICATION

MARK

SWITCH
POSITION

TESTER
CONNECTION

SPECIFIED
CONDITION

Released (ON)

1

−

 2

−

 3

Continuity

Depressed (OFF)

-

No Continuity

1 2 3

ACX01865AB

ON

OFF

DOOR

TSB Revision

BODY

42-54

DOOR TRIM AND WATERPROOF FILM

REMOVAL AND INSTALLATION

M1423004300071

AC000600

3

6

1

9

10

8

7

5

4

2

10

9

10

7

8

4

2

5

6

1

4

7

10

NOTE

: CLIP POSITION

FRONT DOOR

REAR DOOR

A

A

A

A

A

A

A

A

A

A

A

A

A

A

A

A

A

A

A

A

A

A

SEALANT:
        3M™ AAD PART NO. 8625
        OR EQUIVALENT

SEALANT:
        3M™ AAD PART NO. 8625
        OR EQUIVALENT

SEALANT:
        3M™ AAD PART NO. 8625
        OR EQUIVALENT

AB

CLIP

SECTION A – A

REMOVAL STEPS
1. PULL HANDLE BOX
2. INSIDE HANDLE COVER

3. INNER DELTA COVER OR

TWEETER COVER

4. DOOR TRIM

REMOVAL STEPS (Continued)
