TRANSAXLE TSB Revision AUTOMATIC TRANSAXLE OVERHAUL 23B-45 76.Use special tools MB990935 <F4A42> or MB990936 <F4A51> and MB990938 to press in the differential bearing 77.Install the torque converter housing to the transaxle case without applying sealant. Tighten its mounting bolts to the Tightening torque: 48 N ⋅⋅⋅⋅ m (35 ft-lb) 78.Loosen all the bolts, and remove the torque converter housing. Then remove the outer race and the crushed 79.Use a micrometer to measure the thickness of the crushed solder beads and record the measured value. Add 0.045 to NOTE: * is the thickness for the differential case preload. 80.Install the spacer selected in step 71 to the torque converter housing. 81.Use special tools MB990935 <F4A42> or MB990936 <F4A51> and MB990938 to press the outer race into 82.Apply a 2 mm (0.08 inch) diameter bead of sealant (MITSUBISHI Genuine Part number MD974421 or NOTE: Be sure to install the case quickly while the sealant is NOTE: After installation, keep the sealed area away from AKX01076 MB990938 MB990935 AB AKX01104 AKX00958 AKX01076 MB990938 MB990935 AB AKX01077 |
