EMISSION CONTROL TSB Revision ENGINE AND EMISSION CONTROL 17-86 5. If the purge flow volume is less than the standard value, check it again with the vacuum hose disconnected from the EVAPORATIVE EMISSION PURGE SOLENOID M1173001700041 1. Remove the air intake hose <2.4L Engine>. 2. Disconnect the vacuum hose (black, black with red paint mark) from the EVAP purge solenoid. NOTE: When disconnecting the vacuum hose, always place 3. Disconnect the harness connector. purge solenoid (refer to the illustration at left). 5. Check airtightness by applying a vacuum with voltage applied directly from the battery to the EVAP purge solenoid 6. Measure the resistance between the terminals of the EVAP purge solenoid. Standard value: 30 −−−− 34 Ω Ω Ω Ω [at 20 °°°° C (68 °°°° F)] 7. Replace solenoid if resistance is out of specification. CHAMBER CHECK M1173008400030 Remove the vacuum hose and chamber assembly, and check VOLUME AIR FLOW SENSOR CHECK M1173007900076 <2.4L ENGINE> To inspect the sensor, refer to GROUP 13A (2.4L), Multiport BATTERY POSITIVE VOLT- NORMAL CONDITION Applied Vacuum leaks Not applied Vacuum maintained AKX01308 AB A B AKX01309 |
