ON-VEHICLE SERVICE

TSB Revision

MULTIPORT FUEL INJECTION (MFI) <2.4L>

13A-433

Evaporative emission ventilation so-
lenoid

U

Powertrain control module (PCM)

R

Fan controller

N

Power steering pressure switch

K

Fuel tank differential pressure sen-
sor

T

Throttle position sensor

F

Heated oxygen sensor (front)

M

Vehicle speed sensor

D

Heated oxygen sensor (rear)

S

Volume air flow sensor (with built-in
intake air temperature sensor and
barometric pressure sensor)

P

NAME

SYMBOL

NAME

SYMBOL

AK000590 AB

A

B

C

D

E

H

J

K

L

M

N

O

P

Q

R

S

T

U

F

G

I

ACX02471

A

MANIFOLD
DIFFERENTIAL
PRESSURE
SENSOR

IGNITION
FAILURE
SENSOR

AC

AK000083AB

INJECTOR

B

ON-VEHICLE SERVICE

TSB Revision

MULTIPORT FUEL INJECTION (MFI) <2.4L>

13A-434

ACX02513

EGR
SOLENOID
VALVE

EVAPORA-
TIVE
EMISSION
PURGE
SOLENOID
VALVE

AC

C

AC002315

D

VEHICLE
SPEED
SENSOR

AC

ACX02519

E

IDLE AIR
CONTROL
MOTOR

AG

ACX02472

F

THROTTLE
POSITION
SENSOR

AH

ACX02478

G

ENGINE COOLANT
TEMPERATURE SENSOR

AG

ACX02477

H

CAMSHAFT
POSITION
SENSOR

AE

AK000591

I

AB

A/C COMPRESSOR CLUTCH RELAY

MFI RELAY

FUEL PUMP RELAY

ENGINE SPEED
DETECTION
CONNECTOR

ACX02475

J

AF

CRANKSHAFT
POSITION SENSOR

ON-VEHICLE SERVICE

TSB Revision

MULTIPORT FUEL INJECTION (MFI) <2.4L>

13A-435

ACX02520

K

AG

POWER STEERING
PRESSURE SWITCH

AK000094AC

L

IGNITION COIL

ACX02476

M

AG

HEATED OXYGEN
SENSOR (FRONT)

ACX02501

N

FAN CONTROLLER

AF

AK000075AD

O

PARK/NEUTRAL POSITION SWITCH

ACX02480

P

VOLUME AIR
FLOW SENSOR

AH

ACX02447

Q

AG

DATA LINK CONNECTOR

ACX02509

R

AH

PCM

ON-VEHICLE SERVICE

TSB Revision

MULTIPORT FUEL INJECTION (MFI) <2.4L>

13A-436

THROTTLE BODY (THROTTLE VALVE AREA)
CLEANING

M1131001000053

1. Start the engine and warm it up until the coolant is heated to

80

°

C (176

°

F) or higher. Then stop the engine.

2. Remove the air intake hose from the throttle body.

CAUTION

Do not allow cleaning solvent to enter the bypass passage.
3. Plug the bypass passage inlet (arrow) of the throttle body.

4. Spray cleaning solvent into the valve through the throttle

body intake port and leave it for approximately five minutes.

5. Start the engine, rev it several times and then idle it for

about one minute. If the idling speed becomes unstable (or if
the engine stalls) due to the bypass passage being plugged,
slightly open the throttle valve to keep the engine running.

6. If the throttle valve deposits are not removed, repeat steps 4

and 5.

7. Unplug the bypass passage inlet.

8. Attach the air intake hose.

9. Use the scan tool to erase any diagnostic trouble code.

10.Adjust the basic idle speed. (Refer to

P.13A-438

.)

AC002318

S

AD

HEATED OXYGEN
SENSOR (REAR)

ACX02494

T

AG

FUEL TANK
DIFFERENTIAL
PRESSURE
SENSOR

(TOP OF FUEL TANK)

ACX02516

U

AH

EVAPORATIVE EMISSION
VENTILATION SOLENOID

FUEL TANK

AK000112AB
