MULTIPORT FUEL INJECTION (MFI) DIAGNOSIS TSB Revision MULTIPORT FUEL INJECTION (MFI) <3.8L ENGINE> 13B-220 STEP 5. Test the OBD-II drive cycle. (1) Carry out a test drive with the drive cycle pattern. Refer to Diagnostic Function − OBD-II Drive Cycle − Procedure 6 − (2) Check the diagnostic trouble code (DTC). YES : Retry the troubleshooting. DTC P0132: Heated Oxygen Sensor Circuit High Voltage (bank 1, sensor 1) BLA CK BLUE BLA CK TO PCM FROM MFI RELAY PINK AK400900 69 92 4 3 1 RIGHT BANK POWERTRAIN CONTROL B-09 MU802605 2 B-22 Right Bank Heated Oxygen Sensor (front) Circuit B-21 100 99 92 91 93 94 95 96 97 98 101 102 103 104 105 106 107 108 109 110 111 112 113 52 51 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80 81 82 83 1 2 3 4 |
