MULTIPORT FUEL INJECTION (MFI) DIAGNOSIS TSB Revision MULTIPORT FUEL INJECTION (MFI) <2.4L ENGINE> 13A-198 (3) Measure the voltage between terminal No. 92 and ground. • Warming up the engine. When the engine is 2,500 r/min, the output voltage should repeat 0 to 0.8 volt alternately. (4) Turn the ignition switch to the "LOCK" (OFF) position. YES : Go to Step 4. 104 96 94 95 93 92 91 99 98 97 103 102 101 100 108 107 106 105 113 112 111 110 109 AK203091AB POWER PLANT ECU |
