AUTOMATIC TRANSAXLE DIAGNOSIS TSB Revision AUTOMATIC TRANSAXLE 23A-42 LINE PRESSURE ADJUSTMENT M1231001700361 1. Drain the transmission fluid. NOTE: The hydraulic pressure test must be performed 2. Remove the valve body cover. the line pressure to the standard value. The pressure Standard value: 0.98 − 1.05 MPa (142 − 152 psi) 4. Install the valve body cover. Pour in one quart transmission fluid. 5. Repeat the hydraulic pressure test. (Refer to Readjust the line pressure if necessary. DIAGNOSTIC TROUBLE CODE CHART M1231007900330 CAUTION During diagnosis, a DTC code associated with AC006153AB ADJUSTING A/T DTC MFI DTC DIAGNOSIS ITEM REFERENCE 15 P0713 Transmission fluid temperature sensor Open circuit 16 P0712 Short circuit 21 − Crankshaft position sensor system Open circuit Group 13A (P0335 − Crankshaft (P0335 − Crankshaft 22 P0715 Input shaft speed sensor system Short circuit/open circuit 23 P0720 Output shaft speed sensor system Short circuit/open circuit |
