AUTOMATIC TRANSAXLE DIAGNOSIS
TSB Revision
AUTOMATIC TRANSAXLE
23A-34
HYDRAULIC CIRCUIT
M1231008800336
PARKING AND NEUTRAL
1
2
3
4
5
6
6
6
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
R N
P
D
3
2
L
: LINE PRESSURE
: OIL PUMP SUCTION PRESSURE
: TORQUE CONVERTER CLUTCH
PRESSURE
: TORQUE CONVERTER AND LUBRICATION
PRESSURE
: TORQUE CONVERTER CLUTCH SOLENOID
VALVE PRESSURE
1. REVERSE
CLUTCH
2. LOW-REVERSE
BRAKE
3. SECOND
BRAKE
4. UNDERDRIVE
CLUTCH
5. OVERDRIVE
CLUTCH
6. ACCUMULATOR
7. CHECK
BALL
8. TORQUE
CONVERTER
CLUTCH
9. FAIL
SAFE
VALVE
A
10.
FAIL
SAFE
VALVE
B
11. TORQUE
CONVERTER
CLUTCH
CONTROL
VALVE
12.
SWITCH
VALVE
13.
TRANSMISSION
FLUID
COOLER
14.
LUBRICATION
15. LOW-REVERSE PRESSURE CONTROL VALVE
16. SECOND PRESSURE CONTROL VALVE
17. UNDERDRIVE PRESSURE CONTROL VALVE
18. OVERDRIVE PRESSURE CONTROL VALVE
19. TORQUE CONVERTER CLUTCH SOLENOID
VALVE
20. LOW-REVERSE
SOLENOID
VALVE
21.
SECOND
SOLENOID
VALVE
22.
UNDERDRIVE
SOLENOID
VALVE
23. OVERDRIVE SOLENOID VALVE
24. TORQUE CONVERTER PRESSURE
CONTROL VALVE
25. REGULATOR
VALVE
26.
MANUAL
VALVE
27. OIL
FILTER
28. OIL
PUMP
29.
OIL
STRAINER
30. RELIEF
VALVE
31. OIL
PAN
