ON-VEHICLE SERVICE TSB Revision BASIC BRAKE SYSTEM 35A-20 3. Remove the following parts from the caliper support. (1) Pad assembly 4. In order to measure the brake drag force after pad installation, measure the rotary-sliding resistance of the hub 5. Install the pads and caliper assembly, and then check the brake drag force (Refer to DISC BRAKE ROTOR CHECK M1351002900334 CAUTION Disc brakes must be kept within the allowable . AC308592 3 2 1 4 AB 3 2 1 4 4 <FRONT> <REAR> 3 4 3 INSPECTION ITEM REMARK Scratches, rust, saturated lining materials and wear • If the vehicle is not driven for a long period of time, sections of the discs that are not in contact • If grooves and scratches resulting from excessive disc wear are not removed prior to installing a new Run-out Excessive run-out of the discs will increase the pedal Change in thickness (parallelism) If the thickness of the disc changes, this will cause Inset or warping (flatness) Overheating and improper handling while servicing |
