AMBIENT TEMPERATURE SENSOR

TSB Revision

HEATER, AIR CONDITIONING AND VENTILATION

55A-276

AMBIENT TEMPERATURE SENSOR

 REMOVAL AND INSTALLATION

M1554003400108

REMOVAL SERVICE POINT

.

<<A>> AMBIENT AIR TEMPERATURE SENSOR
REMOVAL

Insert a screwdriver into the mounting hole of the front bumper
core to release the clip, and remove the ambient temperature
sensor.

AC306569

1

AB

REMOVAL STEP

•

FRONT BUMPER  ASSEMBLY
AND FRONT BUMPER CORE
(REFER TO GROUP 51, FRONT
BUMPER ASSEMBLY

P.51-2

).

<<A>>

1.

AMBIENT AIR  TEMPERATURE
SENSOR

AC307252

AMBIENT AIR
TEMPERATURE SENSOR

AB

SCREWDRIVER

FRONT BUMPER CORE

COMPRESSOR ASSEMBLY AND TENSION PULLEY

TSB Revision

HEATER, AIR CONDITIONING AND VENTILATION

55A-277

INSPECTION

M1551006300349

.

AMBIENT AIR TEMPERATURE SENSOR CHECK

CAUTION

The ambient air temperature sensor should be checked
with removing it. If the sensor is removed, it is no longer
serviceable.
Measure the resistance between the sensor terminals under at
least two temperatures. The resistance values should meet the
values shown.
NOTE: The temperature should be within the shown range.

COMPRESSOR ASSEMBLY AND TENSION PULLEY

REMOVAL AND INSTALLATION

M1552004100289

AC209942AB

REGISTANCE
k

Ω

10

20

30

40

0

0

20

(32) (68)

TEMPERATURE ˚C (˚F)

40

(104)

60

(140)

-20

(-4)

-30

(-22)

Pre-removal Operation
• Refrigerant Discharging (Refer to

P.55A-260

).

• Front Bumper Under Cover (Refer to GROUP 51, FRONT

BUMPER

P.51-2

).

• Front Under Cover RH (Refer to GROUP 51, UNDER

COVER

P.51-11

).

Post-installation Operation
• Drive Belt Tension Adjustment (Refer to GROUP 00,

Maintenance Service

− Drive Belt

P.00-45

).

• Refrigerant Charging (Refer to

P.55A-260

).

• Front Bumper Under Cover (Refer to GROUP 51, FRONT

BUMPER

P.51-2

).

• Front Under Cover RH (Refer to GROUP 51, UNDER

COVER

P.51-11

).

AC306575

1

AB

25 ± 4 N·m
18 ± 3 in-lb

2

3

N

4

5

7

1, 2

3

A/C compressor oil:
  SUN PAG 56

-Pipe coupling

<2.4 L ENGINE>

COMPRESSOR ASSEMBLY AND TENSION PULLEY

TSB Revision

HEATER, AIR CONDITIONING AND VENTILATION

55A-278

REMOVAL SERVICE POINTS

.

<<A>> FLEXIBLE SUCTION HOSE AND FLEXIBLE
DISCHARGE HOSE DISCONNECTION

CAUTION

As the compressor oil and receiver are highly moisture
absorbent, use a non-porous material to plug the hose and
nipples.
To prevent the entry of dust or other foreign bodies, plug the
dismantled hoses and compressor nipples.

.

<<B>> COMPRESSOR REMOVAL

Take care not to spill any compressor oil when removing the
compressor.

AC206183

N

1

2

3

4

5

6

AB

1, 2

3

A/C compressor oil:
  SUN PAG 56

-Pipe coupling

7

25 ± 4 N·m
18 ± 3 fi-lb

<3.8 L ENGINE>

REMOVAL STEPS

<<A>>

1.

FLEXIBLE SUCTION HOSE
CONNECTION

<<A>>

2.

FLEXIBLE DISCHARGE HOSE
CONNECTION

3.

O-RING

4.

DRIVE BELT

<<B>>

>>A<<

5.

A/C COMPRESSOR

6.

GENERATOR

7.

A/C COMPRESSOR BRACKET

REMOVAL STEPS (Continued)

COMPRESSOR ASSEMBLY AND TENSION PULLEY

TSB Revision

HEATER, AIR CONDITIONING AND VENTILATION

55A-279

INSTALLATION SERVICE POINT

.

>>A<< COMPRESSOR INSTALLATION

If a new compressor is installed, first adjust the amount of oil
according to the procedures described below, and then install
the compressor.
1. Measure the amount [X cm

3

 (X fl.oz) of oil within the

removed compressor.

2. Drain (from the new compressor) the amount of oil

calculated according to the following formula, and then
install the new compressor.
New compressor oil amount = 140cm

2

(4.7 fl.oz)

140 cm

3



− X cm

3

 = Y cm

3

 (4.7 fl.oz.

− X fl.oz. = Y fl.oz)

NOTE: Y cm

3

 (Y fl.oz) indicates the amount of oil in the refrig-

erant line, the condenser, the evaporator, etc.
NOTE: When replacing the following parts at the same times as
the compressor, subtract the rated oil amount of each part from
Y cm

3

 (Y fl.oz) and discharge from the new compressor.

Quantity:

Evaporator: 60 cm

3

 (2.0 fl.oz)

Condenser: 15 cm

3

 (0.5 fl.oz)

Suction hose: 10 cm

3

 (0.3 fl.oz)

Receiver: 10 cm

3

 (0.3 fl.oz)

INSPECTION

M1552014301083

COMPRESSOR AIR CONDITIONING
COMPRESSOR CLUTCH OPERATION CHECK

Connect the compressor connector terminal to the battery posi-
tive (+) terminal and ground the battery’s negative (-) terminal
to the compressor unit. At that time, the air conditioning com-
pressor clutch should make a definite operating sound.

AC206292AB

A/C COMPRESSOR
CLUTCH
CONNECTOR
