POWER SEAT

TSB Revision

CIRCUIT DIAGRAMS

90-250

POWER SEAT

M1901010400450

FUSIBLE
LINK

5

AUDIO SYSTEM
<VEHICLES WITH
AUDIO AMPLIFIER>

·POWER WINDOWS
·SUNROOF

FRONT
HEIGHT

REAR
HEIGHT

FRONT
HEIGHT
MOTOR

REAR
HEIGHT
MOTOR

POWER SEAT
ASSEMBLY

JUNCTION
BLOCK

POWER SEAT

TSB Revision

CIRCUIT DIAGRAMS

90-251

SLIDE

RECLINING

RECLINING
MOTOR

SLIDE
MOTOR

POWER SEAT
SWITCH

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW
SB : SKY BLUE     BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET

HEATED SEAT

TSB Revision

CIRCUIT DIAGRAMS

90-252

HEATED SEAT

M1901010700439

BATTERY

IGNITION
SWITCH (IG2)

RELAY
BOX

JOINT
CONNECTOR (1)

JOINT
CONNECTOR (2)

JUNCTION
BLOCK

HEATED
SEAT
RELAY

JUNCTION
BLOCK

·AUDIO SYSTEM
·AUTOMATIC AIR
 CONDITIONING
 SYSTEM
·ELECTRONIC BRAKE-
 FORCE DISTRIBUTION
 (EBD) AND ANTI-LOCK
 BRAKING SYSTEM (ABS)
 <VEHICLES WITH
 TRACTION CONTROL (TCL)>
·FOG LIGHT
·GLOVE BOX LIGHT
·INVECS-II 4A/T
·MANUAL AIR
 CONDITIONING SYSTEM
·METER AND GAUGE
·MULTI-CENTER DISPLAY
·REAR WINDOW DEFOGGER
 AND DOOR MIRROR HEATER
·RHEOSTAT
·SUPPLEMENTAL
 RESTRAINT SYSTEM (SRS)
·TURN-SIGNAL
 LIGHT AND
 HAZARD WARNING
 LIGHT

TAILLIGHT
RELAY

FRONT-ECU

HEATED SEAT

TSB Revision

CIRCUIT DIAGRAMS

90-253

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE
BR :BROWN     O : ORANGE     GR : GRAY     R : RED     W : WHITE
SB : SKY BLUE     P : PINK      Y : YELLOW     V : VIOLET

RHEOSTAT

HEATED SEAT
SWITCH

JOINT
CONNECTOR (2)

(LH)

(RH)

(FUSE     )

20

JUNCTION
BLOCK

JUNCTION
BLOCK

HEATED SEAT
RELAY
