SPECIAL TOOLS

TSB Revision

POWER STEERING

37-14

SPECIAL TOOLS

M1372000600387

TOOL

TOOL NUMBER
AND NAME

SUPERSESSION APPLICATION

MB991897
Ball joint remover

MB991113-01,
MB990635-01 or
General service
tool

Knuckle and tie rod end ball joint
disconnection
NOTE: Steering linkage puller
(MB990635 or MB991113) is also
available to disconnect knuckle and
tie rod end ball joint.

MB990326
Preload socket

General service
tool

Tie rod end ball joint breakaway
torque check

MB991548
Power steering oil
pressure gauge
adapter (Pump
side)

MB991548-01

Oil pump pressure test

MB991549
Power steering oil
pressure gauge
adapter (Hose
side)

MB991549-01

MB990662
Power steering oil
pressure gauge

MB990662-01

MB990803
Steering wheel
puller

-

Steering wheel removal

MB991006
Preload socket

MB990228-01

Steering gear total pinion torque
check

AC106827

MB990326

MB991548

MB991549

MB990662

MB990803

MB991006

SPECIAL TOOLS

TSB Revision

POWER STEERING

37-15

MB991204
Torque wrench
socket

General service
tool

• Rack support adjustment

• Rack support cover removal

MB990925
Bearing and oil
seal installer set

MB990925-01 or
general service
tool

• Oil seal and bearing installation

• MB990927, MB990938, MB990939

(For details, refer to GROUP 26,
Special Tools

P.26-5

.)

MB991120
Needle bearing
puller

Tool not available Needle roller bearing removal

MD998812
Installer cap

-

Gear housing mounting bushing
removal

MD998813
Installer 100

-

MD998822
Installer adapter

-

MD998368
Bearing installer

-

TOOL

TOOL NUMBER
AND NAME

SUPERSESSION APPLICATION

MB991204

MB990925

MB991120

SPECIAL TOOLS

TSB Revision

POWER STEERING

37-16

MD999569
Camshaft oil seal
installer

-

Gear housing mounting bushing
installation

MB990996
Lower arm bushing
arbor

-

MB991199
Oil seal installer

General service
tool

Oil seal installation

MB991197
Bar (long type)

General service
tool

MB991202
Oil seal and
bearing installer

General service
tool

Needle roller bearing and ball bearing
installation

MB991213
Rack installer

General service
tool

Rack installation

MB991203
Oil seal and
bearing installer

Tool not available Oil seal and bearing installation

TOOL

TOOL NUMBER
AND NAME

SUPERSESSION APPLICATION

B990996

MB991199

MB991197

MB991202

MB991212

MB991203

ON-VEHICLE SERVICE

TSB Revision

POWER STEERING

37-17

ON-VEHICLE SERVICE

STEERING WHEEL FREE PLAY CHECK

M1372001000344

1. With the engine running (hydraulic operation), set the front

wheels straight ahead.

2. Slightly move the steering wheel in both directions and

measure the play on the steering wheel circumference
before the wheels start to move.

Limit: 30 mm (1.2 inch)

3. If the play exceeds the limit, check on the steering shaft and

steering linkage connection. Correct or replace.

4. If the free play still exceeds the limit value, set the steering

wheel straight ahead with the engine stopped. Apply 5 N
(1.1 pound) towards the steering wheel circumference and
check the play.

Standard value (steering wheel play with the engine
stopped): 10 mm (0.4 inch) or less

5. If the play exceeds the standard value, remove the steering

gear (refer to

P.37-33

) and check the total pinion torque

(refer to

P.37-41

).

MB991317
Seal ring installer

Tool not available Seal ring installation

MB991152
Dust cover installer

General service
tool

Oil seal installation

MB991561
Boot band crimping
tool

MB991561

Bellows band installation

TOOL

TOOL NUMBER
AND NAME

SUPERSESSION APPLICATION

MB991317

MB991152

MB991561
