Mitsubishi Galant 9G. Manual - part 1476

SRS AIR BAG DIAGNOSIS

TSB Revision

SUPPLEMENTAL RESTRAINT SYSTEM (SRS)

52B-314

Disconnect passenger’s seat belt switch connector D-29. Then
check continuity between the switch terminals.

Q: Is passenger’s seat belt switch in good condition?

YES : Go to Step 4.
NO :  Replace inner seat belt. (Refer to GROUP 52A, Front

Seat Belt

P.52A-32

.)

ITEM

TESTER
CONNECTION

STANDARD
VALUE

SPECIFIED
CONDITION

Fastened seat
belt

1

− 3

820

± 20 Ω

−

1

− Ground

−

No continuity

3

− Ground

−

No continuity

2

− 3

−

Less than 2
ohms

Unfastened
seat belt

2

− 3

820

± 20 Ω

−

2

− Ground

−

No continuity

3

− Ground

−

No continuity

1

− 3

−

Less than 2
ohms

AC308225

D-29 PASSENGER'S
SEATBELT SWITCH
CONNECTOR

AB

AC308223

D-29 PASSENGER'S
SEATBELT SWITCH
CONNECTOR

AB

SRS AIR BAG DIAGNOSIS

TSB Revision

SUPPLEMENTAL RESTRAINT SYSTEM (SRS)

52B-315

STEP 4. Check the passenger’s seat belt switch circuit
D-29. Measure the resistance at SRS-ECU connector
C-120.
(1) Disconnect passenger’s seat belt switch connector D-29.

(2) Install the passenger’s seat belt to the seat belt switch.

(3) Disconnect SRS-ECU connector C-120 and measure at the

harness side (rear side).

AC305264

AT

CONNECTOR: D-29

HARNESS SIDE

AC308611 AD

D-29 PASSENGER'S
SEAT BELT SWITCH
CONNECTOR

BUCKLE

TONGUE

AC305362

CONNECTOR: C-120

C-120 (Y)

AG

SRS-ECU

63

55

51

69

61

66

58

65

64

56 57

68

60

67

59

70

62

53

52 B

A

54

C-120
Harness side
connector
(rear view)

SRS AIR BAG DIAGNOSIS

TSB Revision

SUPPLEMENTAL RESTRAINT SYSTEM (SRS)

52B-316

(4) Measure the resistance between terminal 52 and terminal

51.
Resistance should be 820

± 82 Ω

(5) Measure the resistance between terminal 52, 51 and body

ground.
It should be open circuit.

(6) Measure the resistance between terminal 65 and terminal

51.
Resistance should be less than 2 ohms.

(7) Remove the passenger’s seat belt from the seat belt switch.

AC305362

CONNECTOR: C-120

C-120 (Y)

AG

SRS-ECU

63

55

51

69

61

66

58

65

64

56 57

68

60

67

59

70

62

53

52 B

A

54

C-120
Harness side
connector
(rear view)

AC308227

63

55

51

69

61

66

58

65

64

56 57

68

60

67

59

70

62

53

52 B

A

54

C-122 HARNESS SIDE
CONNECTOR
(REAR VIEW)

AB

AC310506

63

55

51

69

61

66

58

65

64

56 57

68

60

67

59

70

62

53

52 B

A

54

C-122 HARNESS SIDE
CONNECTOR
(REAR VIEW)

EN

AC308228

63

55

51

69

61

66

58

65

64

56 57

68

60

67

59

70

62

53

52 B

A

54

C-122 HARNESS SIDE
CONNECTOR
(REAR VIEW)

AB

AC308611 AC

D-29 PASSENGER'S
SEAT BELT SWITCH
CONNECTOR

BUCKLE

TONGUE

SRS AIR BAG DIAGNOSIS

TSB Revision

SUPPLEMENTAL RESTRAINT SYSTEM (SRS)

52B-317

(8) Disconnect SRS-ECU connector C-120 and measure at the

harness side (rear side).

(9) Measure the resistance between terminal 65 and terminal

51.
Resistance should be 820

± 82 Ω

(10)Measure the resistance between terminal 65, 51 and body

ground.
It should be open circuit.

(11)Measure the resistance between terminal 52 and terminal

51.
Resistance should be less than 2 ohms.

Q: Does the resistance meet the value above?

YES : Erase the diagnostic trouble code memory, and check

the diagnostic trouble code. If DTC B1530, B1531,
B1532, B1533, B1534, B1535, B1536, B1537, B1538
or B1539 are set, replace the SRS-ECU. (Refer to

P.52B-365

.) Then go to Step 6.

NO :  Go to Step 5.

AC305362

CONNECTOR: C-120

C-120 (Y)

AG

SRS-ECU

63

55

51

69

61

66

58

65

64

56 57

68

60

67

59

70

62

53

52 B

A

54

C-120
Harness side
connector
(rear view)

AC308228

63

55

51

69

61

66

58

65

64

56 57

68

60

67

59

70

62

53

52 B

A

54

C-122 HARNESS SIDE
CONNECTOR
(REAR VIEW)

AB

AC314240

63

55

51

69

61

66

58

65

64

56 57

68

60

67

59

70

62

53

52 B

A

54

C-122 HARNESS SIDE
CONNECTOR
(REAR VIEW)

AC

AC308227

63

55

51

69

61

66

58

65

64

56 57

68

60

67

59

70

62

53

52 B

A

54

C-122 HARNESS SIDE
CONNECTOR
(REAR VIEW)

AB
