GENERAL  –

Major Specifications

00-4

MAJOR SPECIFICATIONS

<3-door model>

2

5

7

9

4

1

8

6

3

<R.H.drive
vehicles>

<L.H.drive
vehicles>

GENERAL  –

Major Specifications

00-5

Items

H66WMNDELA

H66WMNDERA

H66WMRDELA

H66WMRDERA

Vehicle
di

i

Overall length

1 3,735

dimensions
mm

Overall width

2 1,680

mm

Overall height (unladen)

3 1,690/1,725*

1

/1,700*

2

Wheelbase

4 2,280/2,272*

3

Track-front

5 1,435

Track-rear

6 1,445

Overhang-front

7 755

Overhang-rear

8 700

Ground clearance
(unladen)

9 200

Vehicle

i ht k

Kerb weight

1,255

1,275

weight kg

Max. gross vehicle weight

1,680

Max. axle weight
rating-front

710

720

Max. axle weight
rating-rear

545

555

Seating capacity

4

Engine

Model No.

4G93

g

Total displacement mL

1,834

Transmis-

i

Model No.

V5M21

V4AW4

sion

Type

5-speed manual

4-speed automatic

Fuel system

Fuel supply system

Electronically controlled multipoint injection

NOTE:
*

1

: Vehicles with roof rails

*

2

: Vehicles with roof spoiler

*

3

: Measure in running condition

GENERAL  –

Major Specifications

00-6

<5-door model>

2

5

7

9

4

1

8

6

3

<R.H.drive
vehicles>

<L.H.drive
vehicles>

GENERAL  –

Major Specifications

00-7

Items

H76WLNDELA

H76WLNDERA

H76WRNDELA

H76WRNDERA

Vehicle
di

i

Overall length

1 4,035

dimensions
mm

Overall width

2 1,680

mm

Overall height (unladen)

3 1,700/1,735*

1

/1,720*

2

Wheelbase

4 2,450/2,439*

3

Track-front

5 1,435

Track-rear

6 1,445

Overhang-front

7 755

Overhang-rear

8 830

Ground clearance
(unladen)

9 200

Vehicle

i ht k

Kerb weight

1,340

1,360

weight kg

Max. gross vehicle weight

1,840

Max. axle weight
rating-front

735

750

Max. axle weight
rating-rear

605

610

Seating capacity

5

Engine

Model No.

4G93

g

Total displacement mL

1,843

Transmis-

i

Model No.

V5M21

V4AW4

sion

Type

5-speed manual

4-speed automatic

Fuel system

Fuel supply system

Electronically controlled multipoint injection

NOTE:
*

1

: Vehicles with roof rails

*

2

: Vehicles with roof spoiler

*

3

: Measure in running condition
