ENGINE AND EMISSION CONTROL –
Emission Control System <4G93-GDI, 4G13-MPI>
17-3
EMISSION CONTROL SYSTEM <4G93-GDI,4G13-MPI>
GENERAL
OUTLINE OF CHANGES
The service procedures have been established to describe revised sections due to the changed items
shown below.
<4G93-GDI Engine>
The purge control solenoid valve has been changed to the one with increased flow amount, and the
layout of vacuum pipe and other parts has been changed.
<4G13-MPI Engine>
The purge control solenoid valve has been changed from ON/OFF control to duty control, and the
throttle body intake purge port has been changed from the upstream side to the downstream side.
Furthermore, the purge control solenoid valve has been changed to the one with increased flow amount.
The mounting positions of EGR valve and EGR control solenoid valve have been changed.
GENERAL INFORMATION
The evaporative emission control system used in the 4G13-MPI engine has been changed from before.
<4G13-MPI>
Item
Name
Specification
Evaporative emission control system
Canister
Equipped
Purge control solenoid valve
Duty cycle type solenoid valve
(Purpose: HC reduction)
SERVICE SPECIFICATIONS
Item
Standard value
Purge control solenoid valve coil resistance (at 20
C)
Ω
30 – 34
