NOTES

GENERAL INFORMATION

ENGINE LUBRICATION

12-2

GENERAL INFORMATION

M1121000100357

The lubrication method is a fully force-fed, full-flow fil-
tration type. The engine oil pump is a trochoid type
which is driven by the crankshaft <4G1>.The engine
oil pump is a gear type which is driven by the crank-
shaft via the balancer timing belt <4G6>.

ENGINE OILS
Health Warning

Prolonged and repeated contact with mineral oil will
result in the removal of natural fats from the skin,
leading to dryness, irritation and dermatitis. In addi-
tion, used engine oil contains potentially harmful con-
taminants which may cause skin cancer. Adequate
means of skin protection and washing facilities must
be provided.

Recommended Precautions

The most effective precaution is to adapt working
practices which prevent, as far as practicable, the
risk of skin contact with mineral oils, for example by
using enclosed systems for handling used engine oil
and by degreasing components, where practicable,
before handling them. Other precautions:

• Avoid prolonged and repeated contact with oils,

particularly used engine oils.

• Wear protective clothing, including impervious

gloves where practicable.

• Avoid contaminating clothes, particularly under-

pants, with oil.

• Do not put oily rags in pockets, the use of overalls

without pockets will avoid this.

• Do not wear heavily soiled clothing and

oil-impregnated foot-wear. Overalls must be
cleaned regularly and kept separate from per-
sonal clothing.

• Where there is a risk of eye contact, eye protec-

tion should be worn, for example, chemical gog-
gles or face shields; in addition an eye wash
facility should be provided.

• Obtain first aid treatment immediately for open

cuts and wounds.

• Wash regularly with soap and water to ensure all

oil is removed, especially before meals (skin
cleansers and nail brushes will help). After clean-
ing, the application of preparations containing
lanolin to replace the natural skin oils is advised.

• Do not use petrol, kerosine, diesel fuel, gas oil,

thinners or solvents for cleaning skin.

• Use barrier creams, applying them before each

work period, to help the removal of oil from the
skin after work.

• If skin disorders develop, obtain medical advice

without delay.

SERVICE SPECIFICATION

M1121000300232

Item

Standard value

Oil pressure kPa

at idle

29 or more

at 3,500 r/min

294

− 686

LUBRICANT

M1121000400433

Item

Specification

Engine oil ACEA classification

A1, A2 or A3

Engine oil API classification

SG or higher

Engine oil quantity L

4G1

Oil filter

0.3

Total

3.3

4G6

Oil filter

0.3

Total

4.3

SEALANT

ENGINE LUBRICATION

12-3

SEALANT

M1121000500258

Item

Specified sealant

Remark

Oil pressure switch

3M ATD Part No. 8660 or equivalent

Semi-drying sealant

SPECIAL TOOLS

M1121000600675

Tool

Number

Name

Use

B991396

MB991396

Oil filter wrench

Removal and installation
of engine oil filter (When
using the engine oil filter
of MD360935)

MB991828

MB991828

Oil filter wrench

Removal and installation
of engine oil filter (When
using the engine oil filter
of MD348631 and
MD365876)

MB991610

MB991610

Oil filter wrench

Removal and installation
of engine oil filter (When
using the engine oil filter
of MD356000)

MD998012

Oil pressure switch
wrench

Removal and installation
of oil pressure switch
