Mitsubishi Lancer. Manual - part 164

SPARE CONNECTOR (FOR AUDIO)

CIRCUIT DIAGRAMS

90-302

SPARE CONNECTOR (FOR AUDIO) <RHD>

M1901019000523

TWEETER (LH)

TWEETER (RH)

IGNITION
SWITCH (ACC)

BATTERY

FRONT-ECU

TAIL LAMP
RELAY

RELAY
BOX

TAIL LAMP,
POSITION LAMP,
LICENCE PLATE
LAMP AND LIGHTING
MONITOR BUZZER

(LH)

(RH)

FRONT DOOR SPEAKER

SPARE CONNECTOR (FOR AUDIO)

CIRCUIT DIAGRAMS

90-303

·FRONT
 FOG LAMP

·TAIL LAMP,
 POSITION LAMP,
 LICENCE PLATE
 LAMP AND LIGHTING
 MONITOR BUZZER

·HEADLAMP

·WINDSHIELD
 WIPER AND
 WASHER

·REAR FOG LAMP

·HEADLAMP
 LEVELLING
 SYSTEM
·HEADLAMP
 WASHER

ROOF ANTENNA

ANTENNA
AMPLIFIER

ANTENNA

FEEDER

CABLE

SPARE CONNECTOR
(FOR AUDIO)

REAR SPEAKER

NOTE

SEDAN

WAGON

:

:

:

(LH)

(RH)

RHEOSTAT

Wire colour code
B : Black     LG : Light green     G : Green     L : Blue     W : White     Y : Yellow     SB : Sky blue
BR : Brown     O : Orange     GR : Grey     R : Red     P : Pink     V : Violet     PU : Purple

CLOCK

CIRCUIT DIAGRAMS

90-304

CLOCK

M1901007701272

IGNITION
SWITCH (ACC)

RELAY
BOX

BATTERY

·FRONT FOG LAMP
·HEADLAMP
·HEADLAMP LEVELLING SYSTEM
·HEADLAMP WASHER
·REAR FOG LAMP
·TAIL LAMP,
 POSITION LAMP,
 LICENCE PLATE LAMP
 AND LIGHTING
 MONITOR BUZZER
·WINDSHIELD WIPER
 AND WASHER

HEADLAMP

CLOCK

NOTE

: LHD
: RHD

CIGARETTE LIGHTER AND ASHTRAY ILLUMINATION LAMP

CIRCUIT DIAGRAMS

90-305

CIGARETTE LIGHTER AND ASHTRAY ILLUMINATION

LAMP

M1901007801257

IGNITION
SWITCH (ACC)

FRONT-ECU

TAIL LAMP
RELAY

CIGARETTE
LIGHTER

TAIL LAMP,
POSITION LAMP,
LICENCE PLATE
LAMP AND LIGHTING
MONITOR BUZZER

TAIL LAMP,
POSITION LAMP,
LICENCE PLATE
LAMP AND LIGHTING
MONITOR BUZZER

ASHTRAY
ILLUMINATION
LAMP

<LHD>

<RHD>

CIGARETTE LIGHTER
ILLUMINATION
LAMP

METER AND GAUGE

NOTE

: LHD
: RHD

RHEOSTAT

RELAY
BOX
