AUTOMATIC AIR CONDITIONER

CIRCUIT DIAGRAMS

90-274

AUTOMATIC AIR CONDITIONER <RHD> (CONTINUED)

AIR MIXING
DOOR
CONTROL
MOTOR AND
POTENTIOMETER

HEATER
WATER
TEMPERATURE
SENSOR

AIR
THERMO
SENSOR

OUTSIDE
THERMO
SENSOR

INSIDE AIR
TEMPERATURE
SENSOR

DEDICATED IC

DEDICATED IC

OUTSIDE/INSIDE
AIR SELECTION
DAMPER CONTROL
MOTOR

FRONT
SIDE

A/C-ECU

(FUSE     )

5

AUTOMATIC AIR CONDITIONER

CIRCUIT DIAGRAMS

90-275

MODE SELECTION
DAMPER CONTROL
MOTOR AND
POTENTIOMETER

DEDICATED IC

1

FUSIBLE
LINK

DIAGNOSIS
CONNECTOR

DEFOGGER AND
DOOR MIRROR
HEATER

PHOTO SENSOR

Wire colour code
B : Black     LG : Light green     G : Green     L : Blue    W : White
Y : Yellow     SB : Sky blue     BR : Brown    O : Orange
GR : Grey     R : Red     P : Pink     V : Violet    PU : Purple

WINDSHIELD WIPER AND WASHER

CIRCUIT DIAGRAMS

90-276

WINDSHIELD WIPER AND WASHER

WINDSHIELD WIPER AND WASHER <LHD>

M1901006102065

FRONT-ECU

WINDSHIELD
WASHER MOTOR

IGNITION SWITCH (ACC)

(FUSE      )

7

CIRCUIT
BREAKER

WINDSHIELD
WIPER MOTOR

WINDSHIELD
WASHER

WIPER SPEED
SWITCHING
RELAY

WIPER
AUTOMATIC
STOP RELAY

UPPER
SIDE

UPPER
SIDE

WINDSHIELD WIPER AND WASHER

CIRCUIT DIAGRAMS

90-277

ETACS-
ECU

IGNITION SWITCH (IG2)

IGNITION SWITCH (IG1)

BATTERY

POWER
SOURCE

RELAY
BOX

COLUMN
SWITCH

COLUMN-ECU

WINDSHIELD
INTERMITTENT
WIPER INTERVAL
ADJUSTING KNOB

WINDSHIELD
WASHER SWITCH

(WINDSHIELD WIPER SWITCH)
