Mitsubishi Lancer. Manual - part 99

IGNITION SYSTEM

CIRCUIT DIAGRAMS

90-42

IGNITION SYSTEM <4G6-M/T (LHD)>

M1901000603106

IGNITION
SWITCH (IG1)

IGNITION
COIL (1)

IGNITION
COIL (2)

SPARK PLUG

ENGINE-ECU

ENGINE SPEED
DETECTION
CONNECTOR

INPUT SIGNAL

CAPACITOR

·ATMOSPHERIC
 PRESSURE SENSOR
·CAMSHAFT
 POSITION SENSOR

·ENGINE CRANK
 ANGLE SENSOR

·WATER TEMPERATURE
 SENSOR UNIT

·ENGINE CONTROL
 DETONATION SENSOR

·FUEL PRESSURE SENSOR
·IGNITION SWITCH (ST)
·INTAKE AIR
 TEMPERATURE
 SENSOR

·ENGINE CONTROL
 OXYGEN SENSOR

·VEHICLE SPEED SENSOR

·THROTTLE BODY
 THROTTLE SENSOR

IGNITION SYSTEM

CIRCUIT DIAGRAMS

90-43

IGNITION SYSTEM <4G6-M/T (RHD)>

M1901000603117

IGNITION
SWITCH (IG1)

IGNITION
COIL (1)

IGNITION
COIL (2)

SPARK PLUG

ENGINE-ECU

ENGINE SPEED
DETECTION
CONNECTOR

INPUT SIGNAL

·ATMOSPHERIC
 PRESSURE SENSOR
·CAMSHAFT
 POSITION SENSOR

·ENGINE CRANK
 ANGLE SENSOR

·WATER TEMPERATURE
 SENSOR UNIT

·ENGINE CONTROL
 DETONATION SENSOR

·FUEL PRESSURE SENSOR
·IGNITION SWITCH (ST)
·INTAKE AIR TEMPERATURE
 SENSOR

·ENGINE CONTROL
 OXYGEN SENSOR

·VEHICLE SPEED SENSOR

·THROTTLE BODY
 THROTTLE
 SENSOR

BATTERY

IGNITION
COIL RELAY

RELAY
BOX

·ENGINE
 CONTROL
 SYSTEM
·IMMOBILIZER
 SYSTEM

CAPACITOR

IGNITION SYSTEM

CIRCUIT DIAGRAMS

90-44

IGNITION SYSTEM <4G6-A/T (LHD)>

M1901000603128

IGNITION
SWITCH (IG1)

IGNITION
COIL (1)

IGNITION
COIL (2)

SPARK PLUG

ENGINE-
A/T-ECU

ENGINE SPEED
DETECTION
CONNECTOR

INPUT SIGNAL

CAPACITOR

·ATMOSPHERIC
 PRESSURE SENSOR
·CAMSHAFT
 POSITION SENSOR

·ENGINE CRANK
 ANGLE SENSOR

·WATER TEMPERATURE
 SENSOR UNIT

·ENGINE CONTROL
 DETONATION SENSOR

·FUEL PRESSURE SENSOR
·IGNITION SWITCH (ST)
·INHIBITOR SWITCH
·INTAKE AIR
 TEMPERATURE
 SENSOR

·ENGINE CONTROL
 OXYGEN SENSOR

·THROTTLE BODY
 THROTTLE SENSOR

IGNITION SYSTEM

CIRCUIT DIAGRAMS

90-45

NOTES
