ENGINE AND EMISSION CONTROL --
Body
1-6
Wrapping work
No.
Process
Operation Content
1
Continuous peeling of film
The film is peeled off.
2
Water rinse
Sand and dust are removed from the vehicle body and it is
dried thoroughly.
3
Parts where the film is to be reapplied are
checked.
There should be no leftover adhesive, swelling or discolor-
ation of the paint film, or other defects.
4
Treatment of parts where film is to be
reapplied.
Treat the defects on the parts where film is to be reapplied. If
a solvent is used to remove leftover adhesive, wipe off the
solvent thoroughly.
5
Reapplication
1.
Basically, the parts where the film is to be applied should
be the same as the film that is to be applied.
2.
Apply the film from the lower portion of the body, working
upward progressively. Apply pressure using a plastic
squeegee or similar tool.
3.
As necessary, cut the film at the various parts such as
windshield washer nozzles, hood and trunk lid.
Cautions
1.
Apply the film with the body at a temperature of 10 ~ 40
_C. (Workability is good in this temperature range.)
2.
If the outside surface of the film (the side with no adhesive) is brought into direct contact with the paint film and
left in that state, it may result in loss of paint gloss, so make sure the film does not get folded under or other-
wise make contact with the paint film.
3.
Air bubbles and wrinkles do not have a particularly bad influence on the pain film, but every effort should be
made to prevent air bubbles from being trapped under the film by applying pressure from the center of the film
outward toward the edges during application.
4.
To prevent intrusion of rainwater, be sure to press down the overlapping portions and cut ends of the film se-
curely.
3. EXTERIOR
(1) Visually inspect the entire exterior.
1) Paint condition
2) Corrosion, scratches
3) Bent edges, dented panels
(2) Coated surfaces maintenance
Touch up minor paint chips and flaws.
NOTE
For terms of paintwork, refer to page 1-4.
