GENERAL --

Precautions before Service

0-4

SERVICING THE ELECTRICAL SYSTEM

Before replacing a component related to the electrical
system and before undertaking any repair procedures
involving the electrical system, be sure to first disconnect the
negative (--) cable from the battery in order to avoid damage
caused by short-circuiting.

Caution
Before connecting or disconnecting the negative (--)
cable, be sure to turn off the ignition switch and the
lighting switch.
(If this is not done, there is the possibility of
semiconductor parts being damaged.)

APPLICATION OF ANTI-CORROSION AGENTS
AND UNDERCOATS

If oil or grease gets onto the oxygen sensor, it will cause a
drop in the performance of the sensor.
Cover the oxygen sensor with a protective cover when
applying anti-corrosion agents and undercoats.

PRE-INSPECTION CONDITION

“Pre-inspection condition” refers to the condition that the
vehicle must be in before proper engine inspection can be
carried out. If you see the words “Set the vehicle to the
pre-inspection condition”. in this manual, it means to set the
vehicle to the following condition.

D Engine coolant temperature: 80 to 90_C

D Lamps, electric cooling fan and all accessories: OFF

D M/T: Neutral

D A/T: P range

VEHICLE WASHING

If high-pressure car-washing equipment or steam
car-washing equipment is used to wash the vehicle, be sure
to note the following information in order to avoid damage to
plastic components, etc.

D Spray nozzle distance: Approx. 40 cm or more

D Spray pressure: 3,900 kPa or less

D Spray temperature: 82_C or less

D Time of concentrated spray to one point: within 30 sec.

ACX00880AC

Approx.

40 cm

ACX00881AD

GENERAL --

Precautions before Service

0-5

MUT-

II

Refer to the “MUT-

II REFERENCE MANUAL” or “MUT-II

OPERATING INSTRUCTIONS” for instructions on handling
the MUT-

II.

Connect the MUT-

II to the diagnosis connector as shown in

the illustration.

Caution
Turn the ignition switch to the LOCK (OFF) position
before connecting or disconnecting the MUT-

II.

IN ORDER TO PREVENT VEHICLES FROM FIRE

“Improper installation of electrical or fuel related parts could cause a fire. In order to retain the high quality
and safety of the vehicle, it is important that any accessories that may be fitted or modifications/repairs
that may be carried out which involve the electrical or fuel systems, MUST be carried out in accordance
with MMC’s information/Instructions”.

ENGINE OILS
Health Warning

Prolonged and repeated contact with mineral oil will result in the removal of natural fats from the skin,
leading to dryness, irritation and dermatitis. In addition, used engine oil contains potentially harmful
contaminants which may cause skin cancer. Adequate means of skin protection and washing facilities
must be provided.

Recommended Precautions

The most effective precaution is to adapt working practices which prevent, as far as practicable, the risk of
skin contact with mineral oils, for example by using enclosed systems for handling used engine oil and by
degreasing components, where practicable, before handling them.

Other precautions:

D Avoid prolonged and repeated contact with oils, particularly used engine oils.

D Wear protective clothing, including impervious gloves where practicable.

D Avoid contaminating clothes, particularly underpants, with oil.

D Do not put oily rags in pockets, the use of overalls without pockets will avoid this.

D Do not wear heavily soiled clothing and oil-impregnated foot-wear. Overalls must be cleaned regularly

and kept separately from personal clothing.

D Where there is a risk of eye contact, eye protection should be worn, for example, chemical goggles or

face shields; in addition an eye wash facility should be provided.

D Obtain First Aid treatment immediately for open cuts and wounds.

D Wash regularly with soap and water to ensure all oil is removed, especially before meals (skin

cleansers and nail brushes will help). After cleaning, the application of preparations containing lanolin
to replace the natural skin oils is advised.

D Do not use petrol, kerosine, diesel fuel, gas oil, thinners or solvents for cleaning skin.

D Use barrier creams, applying them before each work period, to help the removal of oil from the skin

after work.

D If skin disorders develop, obtain medical advice without delay.

ACX00882AD

ROM pack

MUT-II

sub-assembly

MUT-II

NOTES

1

1-1

PRE -DELIVERY

INSPECTION

CONTENTS

NO T E S CO NCE RNI NG E NT RI E S

2

. . . . . . . . . . . . .

TABLE OF PRE -DELIVERY INSPECTION

2

. . . . .

PAINTWORK TERMS

4

. . . . . . . . . . . . . . . . . . . . . . .

FI RS T S TE P

5

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Connec t ion of Dar k Cur r ent Connec t or

5

. . . . . . . . . .

BO DY

5

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Wr ap F ilm

5

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Ext erior

6

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Operation of Door Locking Systems and
Door Hinges

7

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Operation of Door Mirrors, Windows and
S unr oof

7

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

UNDE R HO O D

8

. . . . . . . . . . . . . . . . . . . . . . . . . . . . .

E ngine O il Lev el

8

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

B r ak e M as t er Cy linder F luid Lev el

8

. . . . . . . . . . . . . .

Clut c h M as t er Cy linder F luid Lev el

8

. . . . . . . . . . . . . .

Was her F luid Lev el

8

. . . . . . . . . . . . . . . . . . . . . . . . . . .

B at t er y Condit ion and Connec t ions

8

. . . . . . . . . . . . . .

P ower S t eer ing F luid Lev el

9

. . . . . . . . . . . . . . . . . . . .

E lec t r ic al W ir ing

9

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

UNDE R V E HI CL E

9

. . . . . . . . . . . . . . . . . . . . . . . . . . .

Ty r e and S par e Ty r e P r es s ur es

9

. . . . . . . . . . . . . . . . .

S us pens ion S y s t em

10

. . . . . . . . . . . . . . . . . . . . . . . . . .

S t eer ing Link age and S plit P ins

10

. . . . . . . . . . . . . . . .

Under B ody

10

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

BE F O RE RO AD T E S T

11

. . . . . . . . . . . . . . . . . . . . . .

S eat A djus t er s and S eat B ac k Lat c hes

11

. . . . . . . . .

I nhibit or S wit c h

11

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

I dle Cont r ol K nob

11

. . . . . . . . . . . . . . . . . . . . . . . . . . . .

I ns t r um ent P anel Cont r ols

11

. . . . . . . . . . . . . . . . . . . .

Meters, Gauges, Warning Lamps and
I ndic at ion Lam ps

11

. . . . . . . . . . . . . . . . . . . . . . . . . . . .

A ir Condit ioning, Heat er and Def r os t er S y s t em

11

. .

W iper s and Was her s

12

. . . . . . . . . . . . . . . . . . . . . . . . .

Operation of Service Brakes and
Parking Brakes

12

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Clut c h O per at ion

13

. . . . . . . . . . . . . . . . . . . . . . . . . . . .

Operation of Seat Belts, Shoulder Belts and
Retractors

13

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

RO AD T E S T

1 4

. . . . . . . . . . . . . . . . . . . . . . . . . . . . .

E ngine P er f or m anc e and E x haus t G as

14

. . . . . . . . .

Tr ans m is s ion in A ll Ranges

14

. . . . . . . . . . . . . . . . . . .

B r ak es

14

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

S t eer ing Cont r ol

14

. . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Vibr at ion and Rat t les

14

. . . . . . . . . . . . . . . . . . . . . . . . .

E lec t r ic al E quipm ent

15

. . . . . . . . . . . . . . . . . . . . . . . . .

F r ee W heeling Hub

15

. . . . . . . . . . . . . . . . . . . . . . . . . .

AFTER ROAD TEST

16

. . . . . . . . . . . . . . . . . . . . . .

I dle S peed

16

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

I gnit ion Tim ing

16

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Radiat or Coolant Lev el

16

. . . . . . . . . . . . . . . . . . . . . . .

Hoses, Fluid Lines and Connections Located
under Hood

16

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Manual Transmission and Transfer (4WD)
O il Lev el

17

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

A ut om at ic Tr ans m is s ion F luid Lev el

17

. . . . . . . . . . . .

Engine, Transmission, Steering Gear Box and
Diff er ent ial f or Leak s

17

. . . . . . . . . . . . . . . . . . . . . . . . .

F r ont and Rear Diff er ent ial O il Lev els

17

. . . . . . . . . . .

Hoses, Fluid Lines and Connections
Loc at ed under Vehic le

17

. . . . . . . . . . . . . . . . . . . . . . . .

FINAL STEPS

1 8

. . . . . . . . . . . . . . . . . . . . . . . . . . . .

Headlam p A im ing

18

. . . . . . . . . . . . . . . . . . . . . . . . . . . .

E quipm ent

18

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

E x t er ior and I nt er ior

18

. . . . . . . . . . . . . . . . . . . . . . . . . .

O wner I ns t r uc t ions

18

. . . . . . . . . . . . . . . . . . . . . . . . . . .
