NOTES

5-1

GROUP 5

SYNTHETIC-RESIN



PARTS

CONTENTS

LOCATION OF SYNTHETIC-RESIN



PARTS



 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5-2

LOCATION OF SYNTHETIC-RESIN PARTS

SYNTHETIC-RESIN PARTS

5-2

 LOCATION OF SYNTHETIC-RESIN PARTS

M4050001000634

The location and material of each of the principal
synthetic-resin parts are shown below.

AB500732

<Sedan>

AB

1

2

3

7

8

10

29

33

34

32

36

38

40

5, 6

30

42

13

14

9

4

17

11

12

41

35

AB300875AD

15

19

20

21

22

25

26

28

37

16

18

31

39

27

24

23

LOCATION OF SYNTHETIC-RESIN PARTS

SYNTHETIC-RESIN PARTS

5-3

No. Part name

Material

Abbreviation
of material

Heat-resistant
temperature
(

°C)

1

Radiator grille

Acrylonitrile butadiene styrene

ABS

80

2

Radiator centre grille

3

Rear spoiler

4

Licence plate garnish

5

Door mirror (body colour)

6

Door mirror (black)

Acrylonitrile styrene acrylate

ASA (AAS)

80

7

Front bumper garnish

8

Roof antenna

Acrylonitrile ethylene styrene

AES

90

9

Headlamp

Polycarbonate

PC

120

10

Rear door outside handle

Polycarbonate+Acrylonitrile
butadiene styrene

PC+ABS
(PC/ABS)

120

− 125

11

Rear door moulding

12

Front door outside handle

13

Front door moulding

14

Front fender moulding

15

Front splash shield

Polyethylene

PE

100

16

Rear splash shield

17

Rear wiper arm

Polyethylene terephthalate

PET

115

18

Instrument panel

Polypropylene

PP

80

19

Front pillar trim

20

Inside rear view mirror

21

Centre pillar trim upper

22

Rear door trim

23

Rear pillar trim

24

Rear end trim

25

Rear scuff plate

26

Front scuff plate

27

Cowl side trim

28

Floor console box

29

Fog lamp bezel

Rubber denatured polypropylene PP+E/P

80

30

Air intake bezel

31

Front door trim

32

Front bumper extension

Talc filled rubber modified
polypropylene

PP+E/P-TD
(HMPP)

80

− 100

33

Front bumper face

34

Rear bumper face

35

Rear bumper extension

36

Side air dam

Talc filled rubber modified
polypropylene (20%)

PP+E/P-TD20

110

37

Centre pillar trim lower

Talc filled polypropylene (10%)

PP-TD10 (PPF) 100

− 120

38

Front deck garnish

Talc filled polypropylene (20%)

PP-TD20 (PPF) 120

− 130
