BODY SEALING LOCATIONS
CORROSION PROTECTION
4-2
BODY SEALING LOCATIONS
M4040001000547
If the sealant application is directly visible on the
outer plate and requires appearance quality of the
application in areas such as the drip rail, pillar, clinch
and so on, then apply the sealant so that it is flat, or
wipe off any excess mounding after the application.
Be careful not to obstruct the water draining hole.
NOTE: The bold dotted line indicates the application
area on the underside.
<SEDAN>
FLOOR
AB500704
AB
1
2
3
14
UPPER BODY
AB500705
4
5
6
7
AB
SIDE BODY
AB500706AB
8
9
10
11
12
13
