SIDE SILL
WELDED PANEL REPLACEMENT
3-22
6. Apply in advance body sealant in the areas shown
in the figure of the instructions when assembling
the side outer panel.
7. Assemble the side outer panel, then cover the
hole and flange with bolt and aluminium tape and
fill the hole with foam materials A and B as shown
in the figure of the instructions.
• FOAM (Hole A): 3M ATD ULTRAPRO
Panel foam-Yellow
• FOAM (Hole B): 3M ATD Super panel filler
8. Wait 2 hours after filling the foam materials to
remove the bolt and aluminium tape, then melt the
foam materials with a soldering gun so a clip, etc.
can thoroughly be inserted in the hole filled with
foam materials.
9. Reference
Depending on the damaged range, it is advisable
to replace the side outer panel and side sill outer
reinforcement parts.
CAUTION
Cut the side sill outer reinforcement 50 mm away
from the cut area of the side outer panel.
AB301075
AB
: Body sealant
AB301076
A
B
B
Wheel house
Side sill
AB
AB301077AB
AB301078 AB
: Cuttable range
