DEFOGGER
CHASSIS ELECTRICAL
54A-506
Tool
Number
Name
Use
MB991955
a. MB991824
b. MB991827
c. MB991910
d. MB991911
e. MB991825
f. MB991826
M.U.T.-III sub-
assembly
a. Vehicle
Communication
Interface (V.C.I.)
b. M.U.T.-III USB
cable
c. M.U.T.-III main
harness A
(Vehicles with CAN
communication
system)
d. M.U.T.-III main
harness B
(Vehicles without
CAN
communication
system)
e. M.U.T.-III measure
adapter
f. M.U.T.-III trigger
harness
CAUTION
For vehicles with CAN
communication, use M.U.T.-III
main harness A to send
simulated vehicle speed. If you
connect M.U.T.-III main harness
B instead, the CAN
communication does not
function correctly.
Diagnosis code, service data and
actuator test check.
MB991223
a. MB991219
b. MB991220
c. MB991221
d. MB991222
Wiring harness set
a. Check harness
b. LED harness
c. LED harness
adapter
d. Probe
Continuity check and voltage
measurement at wiring harness or
connector
a. For checking connector pin
contact pressure
b. For checking power supply
circuit
c. For checking power supply
circuit
d. For connecting a locally
sourced tester
MB991910
MB991826
MB991955
MB991911
MB991824
MB991827
MB991825
a
b
c
d
e
f
DO NOT USE
MB991223
a
d
c
b
DO NOT USE
BA
