Mitsubishi Lancer (4A9 engine). Manual - part 104





COMBINATION METER

CHASSIS ELECTRICAL

54A-78

NOTE: In addition to the operation of M.U.T.-III, the
service reminder warning indicator can be cancelled
by operating the meter information switch on the
combination meter. Refer to .

1. On the "Service Reminder" screen, select "1

Reminder reset (Indicator off)."
NOTE: The screen indicates that the warning
period (Nos. 1 and 2 in the data list) is "0 km" and
"0 month."

2. Press the "OK" button.

3. The current warning indicator is cancelled, and

the next warning period is displayed.
NOTE: The screen indicates that the warning
period (Nos. 1 and 2 in the data list) is "15000 km"
and "12 month."

2. NEXT SCHEDULE REMINDER CANCEL

CAUTION

• If the next warning period is cancelled by mis-

take, the cancelled warning period can be
restored by executing "5 Periodic reminder
schedule set" to set a schedule different from
the current one once, and then returning it to
the previous schedule.

• Only the next schedule can be deleted by exe-

cuting "2. Next schedule reminder cancel".
Schedules cannot be deleted one after
another.

The next warning period is cancelled, and its follow-
ing warning period can be set.

1. On the "Service Reminder" screen, select "2 Next

schedule reminder cancel."
NOTE: The screen indicates that the warning
period (Nos. 1 and 2 in the data list) is "1000 km"
and "1 month."

2. Press the "OK" button.

3. The next warning period is reset, and its following

warning period is set.
NOTE: The screen indicates that the warning
period (Nos. 1 and 2 in the data list) is changed to
"16000 km" and "13 month."

3. EXTRA REMINDER SETTING
In addition to the current warning period, the tempo-
rary service reminder warning period can be set.

1. On the "Service Reminder" screen, select "3 Extra

reminder setting."
NOTE: The screen indicates that the temporary
warning period (Nos. 4 and 5 in the data list) has
not been set.

AC602558

Mileage until reminder

0 km

0 month

Months until reminder

Mileage until Extra
reminder

Months until Extra
reminder

1

1

2

4

5

DBA-CW5WXTHHZ1 2006MY - Service Reminder - 4014308A6

Meter

Selected

Item

Special Function

Name

Value

No.

Service Reminder

Data List

Reminder reset
(Indicator off)

Press the OK button to execute.

AK

AC602558

Mileage until reminder

15000 km

12 month

Months until reminder

Mileage until Extra
reminder

Months until Extra
reminder

1

1

2

4

5

DBA-CW5WXTHHZ1 2006MY - Service Reminder - 4014308A6

Meter

Selected

Item

Special Function

Name

Value

No.

Service Reminder

Data List

Reminder reset
(Indicator off)

Check the result.

BQ

AC602558

Mileage until reminder

1000 km

1 month

Months until reminder

Mileage until Extra
reminder

Months until Extra
reminder

1

2

2

4

5

DBA-CW5WXTHHZ1 2006MY - Service Reminder - 4014308A6

Meter

Selected

Item

Special Function

Name

Value

No.

Service Reminder

Data List

Next schedule
reminder cancel

Press the OK button to execute.

AM

AC602558

Mileage until reminder

16000 km

13 month

Months until reminder

Mileage until Extra
reminder

Months until Extra
reminder

1

2

2

4

5

DBA-CW5WXTHHZ1 2006MY - Service Reminder - 4014308A6

Meter

Selected

Item

Special Function

Name

Value

No.

Service Reminder

Data List

Next schedule
reminder cancel

Check the result.

BR

AC602556

Mileage until reminder

-Input the value-

-Input the value-

Distance to
setting point
Months to
setting point

15000 km

12 month

Months until reminder

Mileage until Extra
reminder

Months until Extra
reminder

1

3

2

4

5

DBA-CW5WXTHHZ1 2006MY - Service Reminder - 4014308A4

Meter

Selected

Item

Special Function

Name

Value

No.

Service Reminder

Data List

Name

Value

Set value

Extra reminder setting

Input the value for the item that you want to
set up, and press the OK button.

BF

COMBINATION METER

CHASSIS ELECTRICAL

54A-79

2. Set the temporary warning period (distance or

month) of the "Set value."
NOTE: Either input of distance or month can exe-
cute the setting.

3. Press the "OK" button.

4. The temporary warning period is set.

NOTE: The screen indicates that "2 month" has
been added to the temporary warning period (No.
5 in the data list). (The distance of No. 4 in the
data list has not been set.)

4. EXTRA REMINDER CANCEL
The temporary service reminder warning period
which has been set can be cancelled.

1. On the "Service Reminder" screen, select "4 Extra

reminder cancel."
NOTE: The screen indicates that "3000 km" and
"2 month" have been set to the temporary warning
period (Nos. 4 and 5 in the data list).

2. Press the "OK" button.

3. The temporary warning period is cancelled.

NOTE: The screen indicates that the temporary
warning period (Nos. 4 and 5 in the data list) has
been cancelled.

5. PERIODIC REMINDER SCHEDULE SET
The service reminder schedule can be changed.
NOTE: In addition to the operation of M.U.T.-III, the
schedule can be changed by operating the meter
information switch on the combination meter. Refer
to .

1. On the "Service Reminder" screen, select "5

Periodic reminder schedule set."
NOTE: The screen indicates that the current
schedule (No. 7 in the data list) has been set to
"EU 1."

2. Set the schedule to be changed from "Set value."
3. Press the "OK" button.

AC602557

2

-Input the value-

Distance to
setting point

Months to
setting point

3

DBA-CW5WXTHHZ1 2006MY - Service Reminder - 4014308A5

Meter

Selected

Item

Special Function

Service Reminder

Name

Value

0

1

2

3

Back

Space

Clear

Tab

6

5

4

7

8

9

Set value

Range: 0-254, Unit: month,

Extra reminder setting

Input the value for the item that you want to
set up, and press the OK button.

AI

AC602558

Mileage until reminder

15000 km

12 month

2 month

Months until reminder

Mileage until Extra
reminder

Months until Extra
reminder

1

3

2

4

5

DBA-CW5WXTHHZ1 2006MY - Service Reminder - 4014308A6

Meter

Selected

Item

Special Function

Name

Value

No.

Service Reminder

Data List

Extra reminder setting

Check the result.

BS

AC602558

Mileage until reminder

15000 km

12 month

3000 km

2 month

Months until reminder

Mileage until Extra
reminder

Months until Extra
reminder

1

4

2

4

5

DBA-CW5WXTHHZ1 2006MY - Service Reminder - 4014308A6

Meter

Selected

Item

Special Function

Name

Value

No.

Service Reminder

Data List

Extra reminder cancel

Press the OK button to execute.

BT

AC602558

Mileage until reminder

15000 km

12 month

Months until reminder

Mileage until Extra
reminder

Months until Extra
reminder

1

4

2

4

5

DBA-CW5WXTHHZ1 2006MY - Service Reminder - 4014308A6

Meter

Selected

Item

Special Function

Name

Value

No.

Service Reminder

Data List

Extra reminder cancel

Check the result.

BU

AC602556

Mileage until reminder

-Input the value-

Schedule Spec.

15000 km

12 month

Months until reminder

Mileage until Extra
reminder

Months until Extra
reminder

1

5

2

EU 1

Current Schedule

7

4

5

DBA-CW5WXTHHZ1 2006MY - Service Reminder - 4014308A4

Meter

Selected

Item

Special Function

Name

Value

No.

Service Reminder

Data List

Name

Value

Set value

Periodic reminder
schedule set

Select the value and press the OK button.

BG

AC602556

Mileage until reminder

EU 2

15000 km

12 month

Months until reminder

Mileage until Extra
reminder

Months until Extra
reminder

1

5

2

EU 1

Current Schedule

7

4

5

DBA-CW5WXTHHZ1 2006MY - Service Reminder - 4014308A4

Meter

Selected

Item

Special Function

Name

Value

No.

Service Reminder

Data List

Name

Value

Set value

Periodic reminder
schedule set

Select the value and press the OK button.

BH

Schedule Spec.

COMBINATION METER

CHASSIS ELECTRICAL

54A-80

4. The schedule is changed.

NOTE: The screen indicates that the current
schedule (No. 7 in the data list) has been changed
to "EU 2."

6. INTEGRATED VALUE ADJUSTMENT
At the combination meter replacement or for the
vehicle with its battery being removed for a long
period (15 days or more), this adjustment is used to
reset the mileage and elapsed days for check warn-
ing.

1. On the "Service Reminder" screen, select "6

Integrated value adjustment."
NOTE: The screen indicates that the current mile-
age and elapsed days (Nos. 8 and 9 in the data
list) are "26 km" and "0 day."

2. To "Set value," input the mileage and elapsed

days to be reset.
NOTE: Always input both the mileage and
elapsed days.

3. Press the "OK" button.

4. The mileage and elapsed days are changed. The

combination meter automatically recalculates the
distance and days to the nearest next check from
the settings of mileage and elapsed days for
check warning, and then displays them in "Data
List."
NOTE:

.

•

The screen indicates that the current mileage
and elapsed days (Nos. 8 and 9 in the data
list) have been changed to "100 km" and "30
day."

•

Set the elapsed days for check warning to "0
day" by the above resetting method, thereby
the timer is reset indirectly.

7. OPTIONAL INT SCHEDULE SETTING

CAUTION

If the current schedule is set to the "Optional
INT" by executing "5. Periodic reminder schedule
set," the "set value" cannot be input. Therefore,
set it to the schedule other than the "Optional
INT" once, and then execute "7. Optional INT
schedule setting."
In addition to the existing schedule, the optional serv-
ice reminder schedule can be set.

1. On the "Service Reminder" screen, select "7

Optional INT schedule setting."
NOTE: The screen indicates that the optional
schedule (Nos. 12 and 13 in the data list) has not
been set.

AC602558

Mileage until reminder

20000 km

12 month

Months until reminder

Mileage until Extra
reminder

Months until Extra
reminder

1

5

2

EU 2

Current Schedule

7

4

5

DBA-CW5WXTHHZ1 2006MY - Service Reminder - 4014308A6

Meter

Selected

Item

Special Function

Name

Value

No.

Service Reminder

Data List

Periodic reminder
schedule set

Check the result.

BV

AC602556

Mileage until reminder

-Input the value-

-Input the value-

Running Distance

Elapsed Days

15000 km

12 month

26 km

0 day

Months until reminder

Mileage until Extra
reminder

Months until Extra
reminder

1

6

2

4

5

8

9

DBA-CW5WXTHHZ1 2006MY - Service Reminder - 4014308A4

Meter

Selected

Item

Special Function

Name

Value

No.

Service Reminder

Data List

Name

Value

Set value

Integrated value
adjustment

Input the value to both items, and press the
OK button.

BI

Integrated mileage for
reminder

Integrated days for
reminder

AC602557

30

100

6

DBA-CW5WXTHHZ1 2006MY - Service Reminder - 4014308A5

Meter

Selected

Item

Special Function

Service Reminder

Name

Value

0

1

2

3

Back

Space

Clear

Tab

6

5

4

7

8

9

Set value

Range: 0-32767, Unit: day,

Input the value to both items, and press the
OK button.

AJ

Running Distance

Elapsed Days

Integrated value
adjustment

AC602558

Mileage until reminder

14900 km

11 month

100 km

30 day

Months until reminder

Mileage until Extra
reminder

Months until Extra
reminder

1

6

2

4

5

Integrated mileage for
reminder

Integrated days for
reminder

8

9

DBA-CW5WXTHHZ1 2006MY - Service Reminder - 4014308A4

Meter

Selected

Item

Special Function

Name

Value

No.

Service Reminder

Data List

Integrated value
adjustment

Check the result.

BW

AC602556

Mileage until reminder

-Input the value-

-Input the value-

Optional INT.
for mileage
Optional INT.
for month

15000 km

12 month

26 km

0 day

Months until reminder

Optional interval for
mileage

Optional interval for
month

1

7

2

12

13

8

9

DBA-CW5WXTHHZ1 2006MY - Service Reminder - 4014308A4

Meter

Selected

Item

Special Function

Name

Value

No.

Service Reminder

Data List

Name

Value

Set value

Optional INT schedule
setting

BJ

Integrated mileage for
reminder

Integrated days for
reminder

Input the value for the item that you want to
set up, and press the OK button.

COMBINATION METER

CHASSIS ELECTRICAL

54A-81

2. Set the optional schedule (distance or month) of

the "Set value."
NOTE: Either input of distance or month can exe-
cute the setting.

3. Press the "OK" button.

4. The optional schedule is set. The set schedule

becomes effective by executing "5 Periodic
reminder schedule set" and setting the schedule
to "Optional INT."
NOTE: The screen indicates that "2 month" has
been added to the optional schedule (No. 13 in
the data list). (The distance of No. 12 in the data
list has not been set.)

Relationship between the elapsed months and the elapsed days which are used by the service
reminder function

NOTE:

.

•

When the number of elapsed days is 0 to 29, the
number of elapsed months is 0.

•

The combination meter performs calculation
using 365.25 days for one year and 30.4375 days
for one month.

HOW TO SET BY SPECIAL OPERATION
OF SWITCH

By operating the meter information switch of the
combination meter, the service reminder warning
cancellation and the schedule setting can be per-
formed.

AC602557

2

7

DBA-CW5WXTHHZ1 2006MY - Service Reminder - 4014308A5

Meter

Selected

Item

Special Function

Service Reminder

Name

Value

0

1

2

3

Back

Space

Clear

Tab

6

5

4

7

8

9

Set value

Range: 0-255, Unit: month,

AK

Optional INT schedule
setting

-Input the value-

Optional INT.
for mileage
Optional INT.
for month

Input the value for the item that you want to
set up, and press the OK button.

AC604401

Mileage until reminder

2 month

2 month

26 km

0 day

Months until reminder

Optional interval for
mileage

Optional interval for
month

1

7

2

12

13

8

9

DBA-CW5WXTHHZ1 2006MY - Service Reminder - 4014308A4

Meter

Selected

Item

Special Function

Name

Value

No.

Service Reminder

Data List

Optional INT schedule
setting

AC

Integrated mileage for
reminder

Integrated days for
reminder

Check the result.
Please set up "Optional INT" in "Periodic
inspection schedule set" function.
When you start the service reminder at this
interval setting.

Numb
er of
month
s

Number of days Numb

er of
month
s

Number of days Numb

er of
month
s

Number of days Numb

er of
month
s

Number of days

1

30

− 60

13

396

− 425

25

761

− 790

37

1 126

− 1 156

2

61

− 90

14

426

− 456

26

791

− 821

38

1 157

− 1 186

3

91

− 121

15

457

− 486

27

822

− 851

39

1 187

− 1 217

4

122

− 151

16

487

− 516

28

852

− 882

40

1 218

− 1 247

5

152

− 182

17

517

− 547

29

883

− 912

41

1 248

− 1 277

6

183

− 212

18

548

− 577

30

913

− 943

42

1 278

− 1 308

7

213

− 243

19

578

− 608

31

944

− 973

43

1 309

− 1 338

8

244

− 273

20

609

− 638

32

974

− 1 003

44

1 339

− 1 369

9

274

− 303

21

639

− 669

33

1 004

− 1 034

45

1 370

− 1 399

10

304

− 334

22

670

− 699

34

1 035

− 1 064

46

1 400

− 1 430

11

335

− 364

23

700

− 730

35

1 065

− 1 095

47

1 431

− 1 460

12

365

− 395

24

731

− 760

36

1 096

− 1 125

48

1 461

− 1 491















Content   ..  102  103  104  105   ..
