SRS AIR BAG DIAGNOSIS TSB Revision SUPPLEMENTAL RESTRAINT SYSTEM (SRS) 52B-139 STEP 6. Short circuit check between the F-28 curtain air DANGER To prevent the air bag from deploying unintentionally, (2) Disconnect curtain air bag module (LH) F-28. Use a flat-tipped screwdriver to unlock the locking button at the (3) Disconnect the D-15 intermediate connector (connection between curtain air bag harness and floor harness). (4) Because the short spring is installed to the D-15 intermediate connector (curtain air bag harness side), insert CAUTION Do not insert a probe into the terminal from its front side connector (curtain air bag harness side) terminal No.1 and Q: Is it open circuit? YES : Replace the curtain air bag module (LH) (Refer to ). Then go to Step 7. NO : Repair the wiring harness. AC609928AB Locking Flat-tipped Inflator Curtain air bag wiring AC700119 D-15 Intermediate 22 mm or more Cable tie Short spring AH AC608812 D-15 Intermediate connector FM |
