DIAGNOSIS <SHIFT LEVER>

TSB Revision

TWIN CLUTCH- SPORTRONIC SHIFT TRANSMISSION (TC-SST)

22C-325

SPECIAL FUNCTION (ACTUATOR TEST REFERENCE TABLE)

M1225027200011

SHIFT LEVER -ECU TERMINALVOLTAGE REFERENCE CHART

M1225007800011

32

Lever
position
(output data)

Shift lever
position
(Output data)

Ignition switch:
ON

Shift lever position: P

P

Shift lever position: P

⇔R

R

−P

Shift lever position: R

R

Shift lever position: R

⇔N

N

−R

Shift lever position: N

N

Shift lever position: N

⇔D

D

−N

Shift lever position: D

D

Shift lever position: Manual
mode

Manual

Shift lever position: Upshift
and hold

+

Shift lever position:
Downshift and hold

−

Item
No.

Display on
scan tool

Item name

Check conditions

Normal
conditions

Item No. Display on

scan tool

Check
items

Test content

Check conditions

Normal
conditions

1

Shift
indicator

Shift
indicator

Display the shift position
requested by the scan tool
for 3 seconds.

• Ignition switch:

ON

• Shift lever

position: P

• Engine: Stopped

The requested
position is
displayed.

2

Back up
light

Back-up
light

Illuminate the back-up light
for 3 seconds.

The back-up light
illuminates.

AC707982AC

C-35

C-27

C-27-1

C-27-2

Connector
number

Term
inal
No.

Check items

Check conditions

Standard value

C-35

3

Shift lock solenoid
power supply

Ignition switch: ON

Battery positive
voltage

Ignition switch: Other than above

1 V or less

4

Stoplight switch

Brake pedal: Depressed

Battery positive
voltage

Brake pedal: Released

1 V or less

5

Ignition switch (ACC)

Ignition switch: ACC

Battery positive
voltage

Ignition switch: Other than above

1 V or less

6

Ground

Always

1 V or less

DIAGNOSIS <SHIFT LEVER>

TSB Revision

TWIN CLUTCH- SPORTRONIC SHIFT TRANSMISSION (TC-SST)

22C-326

C-27

1

CAN_H

−

−

2

CAN_L

−

−

3

R range output

Ignition switch: ON

Shift lever position:
R

Battery positive
voltage

Shift lever position:
Other than above

1 V or less

4

R range input

Always

Battery positive
voltage

5

N range output

Ignition switch: ON

Shift lever position:
N

Battery positive
voltage

Shift lever position:
Other than above

1 V or less

6

Illumination power
supply (for floor console
panel)

Taillight: Turned ON

Battery positive
voltage

Taillight: Turned OFF

1 V or less

7

P/N range input

Always

Battery positive
voltage

8

Ground

Always

−

10

Paddle switch (Down)

Ignition switch: ON

Paddle shift
position: Downshift
and hold

1 V or less

Paddle shift
position: Other
than the above

Battery positive
voltage

11

Paddle switch (Up)

Ignition switch: ON

Paddle shift
position: Upshift
and hold

1 V or less

Paddle shift
position: Other
than the above

Battery positive
voltage

12

Power supply

Always

Battery positive
voltage

13

Ignition switch (IG1)

Ignition switch: ON

Battery positive
voltage

Ignition switch: Other than above

1 V or less

14

Ground to the A/C
illumination

Always

1 V or less

15

P range output

Ignition switch: ON

Shift lever position:
P

Battery positive
voltage

Shift lever position:
Other than above

1 V or less

16

LIN

−

−

Connector
number

Term
inal
No.

Check items

Check conditions

Standard value

DIAGNOSIS <SHIFT LEVER>

TSB Revision

TWIN CLUTCH- SPORTRONIC SHIFT TRANSMISSION (TC-SST)

22C-327

C-27-1

1

D range light

Ignition switch: ON

Shift lever position:
D

1 V or less

Shift lever position:
Other than above

Battery positive
voltage

2

N range light

Ignition switch: ON

Shift lever position:
N

1 V or less

Shift lever position:
Other than above

Battery positive
voltage

3

R range light

Ignition switch: ON

Shift lever position:
R

1 V or less

Shift lever position:
Other than above

Battery positive
voltage

4

P range light

Ignition switch: ON

Shift lever position:
P

1 V or less

Shift lever position:
Other than above

Battery positive
voltage

5

Manual mode light

Ignition switch: ON

Shift lever position:
Manual mode

1 V or less

Shift lever position:
Other than above

Battery positive
voltage

6

Ground to the A/C
illumination

Always

1 V or less

7

Power supply

Always

Battery positive
voltage

10

Power supply to the A/C
illumination

Taillight: Turned ON

Battery positive
voltage

Taillight: Turned OFF

1 V or less

Connector
number

Term
inal
No.

Check items

Check conditions

Standard value

DIAGNOSIS <S-AWC(SUPER ALL WHEEL CONTROL)>

TSB Revision

TWIN CLUTCH- SPORTRONIC SHIFT TRANSMISSION (TC-SST)

22C-328

DIAGNOSIS <S-AWC(SUPER ALL WHEEL CONTROL)>

INTRODUCTION

M1225024900033

For the troubleshooting of S-AWC, refer to GROUP
22A, Manual Transaxle

P.22A-8

.

ON-VEHICLE SERVICE

TRANSMISSION OIL LEVEL CHECK

M1225008000018

1. After cleaning the outer surface of transaxle, visually check

that there is no oil oozing or oil leaking from the transaxle.

2. If an oil oozing or leaking is present, replace the transaxle

assembly.

TRANSMISSION OIL CHANGE

M1225008100015

1. Remove the engine compartment under cover front B

assembly. (Refer to GROUP 51

− Under Cover

P.51-16

.)

C-27-2

1

Twin clutch SST control
mode switch (Down)

Ignition switch: ON

Switch position:
Down (to frontward
of vehicle)
operation, then
hold

1 V or less

Switch position:
Other than above

Battery positive
voltage

2

Twin clutch SST control
mode switch (Up)

Ignition switch: ON

Switch position: Up
(to frontward of
vehicle) operation,
then hold

1 V or less

Switch position:
Other than above

Battery positive
voltage

3

Ground

Always

1 V or less

4

Ground to the A/C
illumination

Always

1 V or less

5

Power supply to the A/C
illumination

Taillight: Turned ON

Battery positive
voltage

Taillight: Turned OFF

1 V or less

Connector
number

Term
inal
No.

Check items

Check conditions

Standard value
