DIAGNOSIS <TC-SST> TSB Revision TWIN CLUTCH- SPORTRONIC SHIFT TRANSMISSION (TC-SST) 22C-269 LOGIC FLOW CHARTS (Monitor Sequence) . DTC SET CONDITIONS Check Conditions • Voltage of battery: 8 V or more. • Voltage of battery: 16.5 V or less. JUDGMENT CRITERIA • Fluid temperature: 150° C (302° F) or more. (400 millisecond) . OBD-II DRIVE CYCLE PATTERN The fluid temperature remains 150 ° C (302° F) or more for 400 milliseconds. . PROBABLE CAUSES • Malfunction of TC-SST-ECU DIAGNOSTIC PROCEDURE STEP 1. Scan tool CAN bus diagnostics YES : Go to Step 2. − Troubleshooting .) After repairing the CAN bus line, go to Step 2. AC710594 START No Yes Yes Good Malfunction END Vehicle condition met No Continuous failure No Fluid temperature > 150 ˚C (302 ˚F) Yes |
