DIAGNOSIS <TC-SST>

TSB Revision

TWIN CLUTCH- SPORTRONIC SHIFT TRANSMISSION (TC-SST)

22C-125

LOGIC FLOW CHARTS (Monitor Sequence) <Shift fork 2 current gear: 5th gear>

DTC SET CONDITIONS <SHIFT FORK 2
CURRENT GEAR: 5TH GEAR>

Check Conditions

• Voltage of battery: 8 V or more.

• Voltage of battery: 16.5 V or less.

• Engine speed: 500 r/min or more.

• Time since above engine condition: 400 millisec-

ond or more.

• Input shaft 1 (odd) speed: 500 r/min or more.

• Shift fork 2 current gear: 5th gear.

• Synchro (5th gear) slip speed: 80 r/min or more.

• Requested shift fork: Not shift fork 2.

JUDGMENT CRITERIA

• Shift fork 2 position: 6 mm (0.24 inch) or less.

(250 millisecond)

OBD-II DRIVE CYCLE PATTERN <SHIFT
FORK 2 CURRENT GEAR: 5TH GEAR>

The travel distance of the shift fork 2 remains 6 mm
(0.24 inch) or more for 250 milliseconds.

AC710682

START

Good

Malfunction

END

Monitoring condition met

Continuous failure
for 250 msec

Yes

Shift fork position
< 6 mm (0.24 inch)

DIAGNOSIS <TC-SST>

TSB Revision

TWIN CLUTCH- SPORTRONIC SHIFT TRANSMISSION (TC-SST)

22C-126

LOGIC FLOW CHARTS (Monitor Sequence) <Shift fork 2 current gear: 3rd gear>

DTC SET CONDITIONS <SHIFT FORK 2
CURRENT GEAR: 3RD GEAR>

Check Conditions

• Voltage of battery: 8 V or more.

• Voltage of battery: 16.5 V or less.

• Engine speed: 500 r/min or more.

• Time since above engine condition: 400 millisec-

ond or more.

• Input shaft 1 (odd) speed: 500 r/min or more.

• Shift fork 2 current gear: 3rd gear.

• Synchro (3rd gear) slip speed: 80 r/min or more.

• Requested shift fork: Not shift fork 2.

JUDGMENT CRITERIA

• Shift fork 2 position: −6 mm (−0.24 inch) or more.

(250 millisecond)

OBD-II DRIVE CYCLE PATTERN <SHIFT
FORK 2 CURRENT GEAR: 3RD GEAR>

The travel distance of the shift fork 2 remains

−6 mm

(

−0.24 inch) or less for 250 milliseconds.

PROBABLE CAUSES

• Malfunction of TC-SST-ECU

DIAGNOSTIC PROCEDURE

STEP 1. Scan tool CAN bus diagnostics
Using scan tool MB991958, diagnose the CAN bus lines.
Q: Is the check result normal?

YES : Go to Step 2.
NO : Repair the CAN bus lines. (Refer to GROUP 54C

−

Troubleshooting

P.54C-14

.) After repairing the CAN

bus line, go to Step 2.

AC710683

START

Good

Malfunction

END

Monitoring condition met

Continuous failure
for 250 msec

Yes

Shift fork position
> -6 mm (-0.24 inch)

DIAGNOSIS <TC-SST>

TSB Revision

TWIN CLUTCH- SPORTRONIC SHIFT TRANSMISSION (TC-SST)

22C-127

STEP 2. Check whether the DTC is reset.
Q: Is DTC No. P1829 set?

YES : Replace the TC-SST assembly. (Refer to

P.22C-341

NO : Intermittent malfunction. (Refer to GROUP 00

− How

to Cope with Intermittent Malfunction

P.00-15

DTC P182A: Shift Fork Position Sensor 3 System (Voltage low range out)

CAUTION

• If there is any problem in the CAN bus lines,

an incorrect diagnostic trouble code may be
set. Prior to this diagnosis, diagnose the CAN
bus lines.

• Whenever the ECU is replaced, ensure that

the CAN bus lines are normal.

DIAGNOSTIC FUNCTION

TC-SST-ECU checks that the voltage of the shift fork
position sensor 3 is normal.

DESCRIPTIONS OF MONITOR METHODS

The voltage of the shift fork position sensor 3 is too
low.

MONITOR EXECUTION

• Continuous

MONITOR EXECUTION CONDITIONS
(OTHER MONITOR AND SENSOR)

Other Monitor (There is no temporary DTC stored

in memory for the item monitored below)

• P182B: Shift fork position sensor 3 system (Volt-

age high range out)

• P182C: Shift fork position sensor 3 system (Out-

put range out)

• P182D: Shift fork position sensor 3 system (Neu-

tral)

• P182E: Shift fork position sensor 3 system (Poor

performance)

• P1844: Shift fork 3 malfunction

• P1852: Shift fork 1 or 2 opposite direction move-

ment

• P1855: Shift fork 3 or 4 opposite direction move-

ment

• P1858: Even number gear axle interlock

• P1876: Gear block 1st

• P1877: Gear block 2nd

• P1878: Gear block 3rd

• P1879: Gear block 4th

• P187A: Gear block 5th

• P187B: Gear block 6th

• P187C: Gear block reverse

Sensor (The sensor below is determined to be

normal)

• Not applicable

DIAGNOSIS <TC-SST>

TSB Revision

TWIN CLUTCH- SPORTRONIC SHIFT TRANSMISSION (TC-SST)

22C-128

LOGIC FLOW CHARTS (Monitor Sequence)

DTC SET CONDITIONS

Check Conditions

• Voltage of battery: 8 V or more.

• Voltage of battery: 16.5 V or less.

JUDGMENT CRITERIA

• Position sensor voltage: 0.128 V or less. (160 mil-

lisecond)

OBD-II DRIVE CYCLE PATTERN

The position sensor voltage remains 0.128 V or more
for 160 milliseconds.

PROBABLE CAUSES

• Malfunction of TC-SST-ECU

DIAGNOSTIC PROCEDURE

STEP 1. Scan tool CAN bus diagnostics
Using scan tool MB991958, diagnose the CAN bus lines.
Q: Is the check result normal?

YES : Go to Step 2.
NO : Repair the CAN bus lines. (Refer to GROUP 54C

−

Troubleshooting

P.54C-14

.) After repairing the CAN

bus line, go to Step 2.

STEP 2. Check whether the DTC is reset.
Q: Is DTC No. P182A set?

YES : Replace the TC-SST assembly. (Refer to

P.22C-341

NO : Intermittent malfunction. (Refer to GROUP 00

− How

to Cope with Intermittent Malfunction

P.00-15

AC710676

START

Good

Malfunction

END

Monitoring condition met

Continuous failure
for 160 msec

Yes

Shift fork position
< 0.128 V
