DIAGNOSIS <TC-SST> TSB Revision TWIN CLUTCH- SPORTRONIC SHIFT TRANSMISSION (TC-SST) 22C-45 DTC P0843: Clutch 1 Pressure Sensor System (Output high range out) CAUTION • If there is any problem in the CAN bus lines, an incorrect diagnostic trouble code may be • Whenever the ECU is replaced, ensure that the CAN bus lines are normal. . DIAGNOSTIC FUNCTION TC-SST-ECU checks that the clutch 1 pressure sen- . DESCRIPTIONS OF MONITOR METHODS The output of the clutch 1 pressure sensor is too . MONITOR EXECUTION • Continuous . MONITOR EXECUTION CONDITIONS Other Monitor (There is no temporary DTC stored in memory for the item monitored below) • P0841: Clutch 1 pressure sensor system (Poor performance) • P0842: Clutch 1 pressure sensor system (Output low range out) • P0753: Shift select solenoid 1 system (Open cir- cuit) • P0973: Shift select solenoid 1 system (Short to ground) • P0974: Shift select solenoid 1 system (Short to power supply) • P2733: Clutch/shift switching solenoid 1, spool stuck • P2736: Clutch/shift switching solenoid 1 system (Open circuit) • P2738: Clutch/shift switching solenoid 1 system (Short to ground) • P2739: Clutch/shift switching solenoid 1 system (Short to power supply) • P181B: Clutch 1 (Pressure low range out) • P181C: Clutch 1 (Pressure high range out) • P1859: Disengagement too late with clutch 1 • P181E: Clutch 2 (Pressure low range out) • P181F: Clutch 2 (Pressure high range out) • P185B: Disengagement too late with clutch 2 • P185D: Clutch open not possible Sensor (The sensor below is determined to be normal) • Shift select solenoid 1 • Clutch/shift switching solenoid 1 . |
